Sell Cut to Length Line

Place of Origin	China

Model No.:JKC-1300
Product Origin:China
Brand Name:King Jime
Price Terms:FOB
Payment Terms:L/C
Certification:
Description:Specifications: 1) Models: KJC 2) Material width (mm): 1000/1250/1,300 / 1,600 / 2,000 3) Material thickness (mm): 0.6 - 6.0mm 4) Coil load (kg): 2,000 / 3,000 / 7,000 / 10,000kg 5) Coil inner diameter (mm): 508 6) Coil outer diameter (mm): 1,200 7) Speed (m/min): 15-20 8) Straightening precision 9) Coil expansion: hydraulic 10) Gauge precision: +/-1.0 11) Power motor (kW): 100 12) Coil car: optional 13) Air hold down arm: stander I. General Induction. Cut To Length Lines can do uncoiling, straightening, gauging, cross-cutting to length and stacking work. It mainly includes uncoiler, straightener, gauge, shearer, conveyor, stacker, hydraulic system, pneumatic system and electrical system, etc., the line can make sure of accurate feeding and shearing. It can be widely used in cold or hot rolling carbon steel, tinplate, stainless steel and all the other kinds of metal materials with surface coating. Cut to length line is controlled by PLC system. It has CNC controlled single shaft feeder, The information of length, shearing numbers and speed can be input to the CNC systems. When the need shearing number is reached the line can stop automatically. The line speed can be adjusted, It has a gauge with high precision, and whole line can work automatically and operate easily, smooth sheet can be made. Outer packing: Wooden cases
