Home > Products > Digital LED Billboard > Custom Dynamic Electronic Digital LED Billboard For Business 1R1G1B
Custom Dynamic Electronic Digital LED Billboard For Business 1R1G1B
- T/T L/C D/P D/A
- 7 days
You May Like
-
SMD High Definition Mobile Digital LED Billboard With Refresh Rate 2000Hz / s
-
Advertising Wireless Waterproof Digital LED Billboard W 10.08 X H 5.04 inch
-
8 MM IP65 SMD Waterproof Digital LED Billboard For Bus Station
-
Weatherproof Programmable Build LED Display / LED Outdoor Screen For Train Station
-
P8 RGB Waterproof Mobile Digital LED Billboard Outside W 40 H 40 dots
-
Waterproof Stadium LED Display / Programmable LED Signs For Advertisement
Product Details
| Brand Name | Ocolour | Place of Origin | China | |
| Model Number | OC-FA-P8DIP246 |
Product Description
Certification:CE/RoHS/FCC/ETL/TUV
?Custom Dynamic Electronic Digital LED Billboard ?For Business 1R1G1B
?
Quick Viewing:?
Maximum power consumption is less than 83.61W/sq.ft (900W/㎡);
Average power consumption is between 30.67w per square feet and 41.81w per square feet;
Module pixel configuration of W 32 × H 16 dots;
Module size is W 10.08 X H 5.04 inch (W 256 × H 128 mm);
More than 90% of pixel & module lightness uniformity;
Less than 1/ 10?? of pixel out of control, dispersion state;
More than 5000hours meant time to failure;
Cabinet size and color could be adjustable by demands;
?
Detailed Description:
With the brightness higher than 6500cd/M2, our outdoor LED display is able to be installed in different environments. Besides that, our display can change the brightness automatically upon the multifunctional card. On the aspects of design, we confirm environmental protection and energy saving philosophy.
Feature Advantage?
With front maintenance, usually one cabinet composes one display;
Front maintenance saves space instead of rear maintenance;
Easy to install, usually adopt for wall-mounted installation;
Energy-saving by using excellent driving IC and improved PCB design;
Working lifespan is at least 100000 hours;
Suitable for almost all type of colors;
Cabinet size can be customized.
?
Popular Application:
This outdoor advertising LED billboards display would be installed for outdoor ads.
?
Specifications:
Item | Technical Parameters |
Screen model | OC-FA-P8DIP246 |
Led encapsulation | DIP246 |
Led configuration | 1R1G1B |
Pixel pitch(mm/inch) | 8mm / 0.31 inch |
Red chip | Wavelength range: 622-631nm, 5nm; |
Green chip | Wavelength range: 460-470nm, 4nm; |
Blue chip | Wavelength range: 521-530nm, 4nm; |
Resolution | 1452dots/sq.ft (15625dots/㎡) |
Maintenance | Front-maintained |
Brightness: CD/sq.ft (CD/㎡) | >603.87CD/sq.ft (6500 CD/㎡) |
Refreshing frequency: Hz | >960 Hz |
Grey scale | 14bit |
Module pixel | W 32 × H 16 dots |
Module size | W 10.8 X H 5.04 inch (W 256 × H 128 mm) |
Viewing angle | Horizontal: 110°, Vertical: 55° |
Cabinet material | Aluminum/steel |
Lightness uniformity | Pixel & module>90% |
Cabinet size | Cabinet size could be adjustable by demands. |
Cabinet color | Customized |
Driving method | 1/4 scan constant current |
Driving IC | MBI5041/MBI5024/JXI5020 |
Power supply | 85-264VAC, typical value: 110VAC/220VAC |
Max consumption | Max.≤83.61W/sq.ft (900W/㎡) |
Average consumption | Ave.: 30.67-41.81w/sq.ft(Ave.:330-450w/㎡) |
Led life time | ≥100000hours |
Mean time to failure | ≥5000hours |
Module plainness | ≤1mm |
Pixel out of control | less than 1/ 10??, dispersion state |
Working temperature | -30oC to +60oC |
Working humidity | 20% to 90% |
Waterproof IP | lamp & top:IP65, other part:IP54 |
Protection function | dampproof/dust-free/anti high temp/anti-thunder/ anti electromagnetic interference, etc |
Certificate | CCC /CE/UL/Rohs/Tuv |
Hardware interface | Standard PC network interface technology/U disc/3G |
Display mode | 24 bit true color |
Colors | 281 trillion colors |
Colour processing ability | ≥14bit |
Color temperature | 3000K ≤ TC ≤9000K, adjustable |
Brightness regulating degrees | continuously adjustable step |
