Electronic Advertising Full Color Digital LED Billboard For Roadside
- T/T L/C D/P D/A
- 7 days
You May Like
-
Renta Commercial LED Displays / Advertising Truck Mounted LED Screen
-
Energy Saving RGB Outdoor LED Billboard / Rental LED display For Public
-
Wireless High Resolution Programmable Digital LED Billboard Rental CE / ROHS
-
1R1G1B Moving LED Screen Pixel Pitch / DIP Electronic LED Message Display
-
10 MM 3G Advertising Programmable LED Display With Large Viewing
-
P10 Commercial Electronic Mobile LED Billboard Convenient High Brightness
Product Details
| Brand Name | Ocolour | Place of Origin | China | |
| Model Number | OC-FA-P10DIP346 |
Product Description
Certification:CE/RoHS/FCC/ETL/TUV
Electronic Advertising Full Color Digital LED Billboard For Roadside
Quick Viewing:
1. MBI5041/MBI5024/JXI5020 of driving IC available;
2. With 85-264VAC large scale switching power supply input, typical value: 110VAC/220VAC;
3. Maximum power consumption is less than 60.39W/sq.ft (650W/㎡);
4. Led lamp lifespan is more than 100000 hours;
5. Less than 1mm module plainness;
6. More than 90% of pixel & module lightness uniformity;
7. Less than 1/ 10?? of pixel out of control, dispersion state;
8. More than 5000hours meant time to failure.
Detailed Description:
With the brightness higher than 7000CD per square meter, our outdoor LED display is able to be installed in different environments. Besides that, our display can change the brightness automatically upon the multifunctional card. On the aspects of design, we confirm environmental protection and energy saving philosophy.
With operating temperature between -30℃-60℃, LED display is able to be installed in any environments and our products even can be able to operate in coastal place with high temperature and high salt degree.
Popular Application:
This outdoor advertising LED display would be installed for outdoor roadside?advertising.
Specifications:
|
Item |
Technical Parameters |
|
Screen model |
OC-FA-P10DIP |
|
Led encapsulation |
DIP346 |
|
Led configuration |
1R1G1B |
|
Pixel pitch(mm/inch) |
10mm / 0.39 inch |
|
Red chip |
Wavelength range: 619-628nm, 5nm; Brightness range:700-1000mcd |
|
Green chip |
Wavelength range: 461-470nm, 4nm; Brightness range: 1400-1700mcd |
|
Blue chip |
Wavelength range: 522-531nm, 4nm; Brightness range: 350-500mcd |
|
Resolution |
929dots/sq.ft (10000dots/㎡) |
|
Maintenance |
Front-maintained |
|
Brightness: CD/sq.ft (CD/㎡) |
>650CD/sq.ft (7000 CD/㎡) |
|
Refreshing frequency: Hz |
>960 Hz |
|
Grey scale |
14bit |
|
Module pixel |
W 32 × H 16 dots |
|
Module size |
W 12.60 X H 6.30 inch (W 320 × H 160 mm) |
|
Viewing angle |
Horizontal: 110°, Vertical: 55° |
|
Cabinet material |
Aluminum/steel |
|
Lightness uniformity |
Pixel & module>90% |
|
Cabinet color |
Customized |
|
Driving method |
1/4 scan constant current |
|
Driving IC |
MBI5041/MBI5024/JXI5020 |
|
Cabinet size |
Cabinet size could be adjustable by demands |
|
Power supply |
85-264VAC, typical value: 110VAC/220VAC |
|
Max consumption |
Max.≤60.39W/sq.ft (650W/㎡) |
|
Average consumption |
Ave.: 20.07-30.19w/sq.ft(Ave.:216-325w/㎡) |
|
Led life time |
≥100000hours |
|
Mean time to failure |
≥5000hours |
|
Module plainness |
≤1mm |
|
Pixel out of control |
less than 1/ 10??, dispersion state |
|
Working temperature |
-30oC to +60oC |
|
Working humidity |
20% to 90% |
|
Waterproof IP |
lamp & top:IP65, other part:IP54 |
|
Protection function |
dampproof/dust-free/anti high temp/anti-thunder/ anti electromagnetic interference, etc |
|
Certificate |
