Home > Products > Automatic Straw Making Machine > Customized Automatic Straw Making Machine Plastic Pipe Making Machine
Customized Automatic Straw Making Machine Plastic Pipe Making Machine
US$ 8800 - 9000/
/ Piece
1 Piece(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
OEM Single Color Plastic Drinking Straw Making Machine Labor Saving
-
Automatic Counting U Shape Drinking Straw Packing Machine / Equipment
-
Full Automatic Straw Making Machine with Single Screw 600-1200pcs/min
-
High Capacity Three Color Automatic Straw Making Machine Pipe Extruder Machine
-
2~50pcs Multiple Drinking Straw Packaging Machine with Bopp Film
-
Auto Three Sides Sealing Straw Packing Machine 1.8m0.8m1.7m
Product Details
| Brand Name | Depai | Place of Origin | China | |
| Model Number | DP-DS01-2 |
Product Description
Certification:CE/ISO9001
Low Cost , Single Color Drinking Straw Making Machine , OEM Service
Description:
DP-DS01 series Single color straw making machine?is composed of main body, tooling, cooling system, cutting machine, with a variety of models such as single color extrusion line, two color and two color co-extrusion line, three color extrusion line, etc.
Quick Details:
High production efficiency Running stably and reliably, working life is long Machine can keep working for long time 1 year warranty Labor saving Easy to operate and controlCharacteristics
Wide?application: drinking?straw,?candy?bar,?pen?riffel,?cotton swab stick etc. Easy?to?operate.?One?operator?is?enough?to?run?the?whole?line? Cut?form:?Diversified cut-end:?90°?/90°?,?90°?/45°?,?90°?/60°?,?45°?/45°?,?60°?/60°? With?stable?output?and?wide?range?of?color?options. Optional Machine: L-type straw collecting machineQuality Control
1. ISO9001 quality certification system
2. Starting from the procurement of raw materials, to finished machine out of the warehouse, every program need to be done initial inspection and re-inspection. After the completion of the finished product, each machine is tested and debugged by professional testers, to achieve the best working condition.
3. Comply with food-grade materials
4. One-year warranty on the entire service
5. Provide professional pre-service training and on-site guidance?
SPECIFICATION:
| Model | DP-DS01-1 | DP-DS01-2 | DP-DS01-3 |
| Color | Single color? | Bi-color | Tri-color |
| Main parts | Extruder, cooling water tank, hauling & cutting system, (vacuum equipment, aircompressor) | ||
| Power?supply | Main?screw? | 380v, 3phase, 50hz, 7.5kw (VFD)? | |
| Sub-screw | / | 0.75 kw | 0.75 kw×2 |
| Heating | 9 kw | 12 kw | 15 kw |
| Hauling?motor | 0.75 kw(VFD) | ||
| Cutting?motor | 0.75 kw(VFD) | ||
| Total power | 19.5 kw | 23.5 kw | 27.5 kw |
| Temperature?Controller | 5 sets | 8 sets | 11 sets |
| Electric?control?cabinet | 1 set | 1 set | 1set |
| AutomaticCounting?Device | 1 set? | 1 set | 1set |
| Way?of?Hauling? | By?rubber?roller | ||
| Way?of?cutting | Rotatory?cutting | ||
| Cooling?water?tank | Usually?3.5m,?can?be?adjust into 4.5m or 6m? | ||
| Specification of?Pipe |
Material | PP?PE?etc. | |
| Diameter | 2mm~13mm, others can be customized | ||
| Length | Adjustable | ||
| Capacity | 600~1000pcs/min | ||
| Color | Single | Two | Three |
| Straight?or?spiral?strips | √ | √ | √ |
| Cutting?End | 90°/90°,90°/45°,90°/60°,45°/45°,60°/60 | ||
| Optional parts | Vacuum Pump (0.75 kw) | Air compressor (3 kw) | |
| Machine dimension (L×W×H) | 2.2m×1m×1.3m | 2.2m×1.3m×1.5m | 2.2m×1m×1.7m |
| Production line?dimension?(L×W×H) | 9m×1m×1.7m | 9m×1.3m×1.7m | 9m×1.6m×1.7m |
| Weight?of?equipment | 1000 kg | 1300 kg | 1500 kg |
REMARKS:
Packaging method: wooden case or as your requests Loading port: Shanghai, Ningbo or as your requests Delivery time: 7-15 days for goods in stock, 30 days for new Trade?terms: FOB, C&F Payment terms: T/T, L/C Contact: jackiexxx@depaimachinery.comContact Us
- Hangzhou Depai Machinery Co., Ltd.
- Contact nameMr. Vincent Zheng Chat Now
- Phone86-571-88964701
- AddressGaosha road, Xiasha Economic and Technological Development Zone, Hangzhou, Zhejiang, China, Hangzhou, Zhejiang
