380V 50HZ 8kw Baby Cotton Buds Making Machine Plastic Pipe Extruder Machine

FOB Price

US$ 11500 - 24000 / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Depai		Place of Origin	China
Model Number	DP-CS-01S

Product Description

Delivery Time:25-35 Days
Certification:CE/ISO
Bady Cotton Bud / Cotton Bud Making Machine with Packing / Bamboo Stick

Description?

This machine makes usage of the computer PLC procedure, and dry by red sunlight, drying during the production. And through getting into the machine for packing part, then reach open, cotton feeding, molding, drying and packing, then save the production time and save staffs.

Packing part can have three choices, PE bag, round tin, square box .change packing module to arrive packing target easy.

Quick Details:

High production efficiency Running stably and reliably, working life is long Machine can keep working for long time 1 year warranty Labor saving Easy to operate and control

Characteristics

The swab mold is provided with installation and demolition, automatic position functions. No need to be adjusted. The power of the whole set of machinery is 8kw. Actual power dissipation is 7kw, conserving more power. Molds self-pressure forming make swab appearance more beautiful, to reduce the defective rate. Automatically counting and tracking the speed, no need to be adjusted.

SPECIFICATION:

Model	DP-CS-01	DP-CS-01S
Production capacity	800-900 pcs/min	900-1200 pcs/min
Main Parts	Touch-screen control panel, PLC Servo motor Servo drivers air cylinder Electromotor Low voltage blower Magnetic valve Sensors	Touch-screen control panel Mitsubishi PLC DELTA inverter YZZ air cylinder Electromotor Medium voltage centrifugal blower Peristaltic glue pump Magnetic valve Sensors
Damageable parts	1. Air valve??????????????????????????????????? 2. Magnetic valve 3. Metal sensor???????????????????????????? 4. Open tooth heating tube 5. Feeding box brush??????????????????? 6. Pipe of glue pump 7. Electric heater????????????????????????? 8. Cotton suwb gripper
Power supply	380V. 3phase.
Drying power	9kw (Open-type warm air drying)	7kw (Close-type circulating air drying)
Total power	10kw	8kw
Suitable Cotton strip	1.5gsm
Suitable Stick size	length 72mm(±1mm), diameter:2.3—2.4mm, weight:15g
Shape of cotton buds	Single head, Double head.
Suitable stick	Plastic stick, Paper stick, Wooden stick, Bamboo stick
manner of packing	zip-lock bag, cylindric box, square box, cardboard box??
Production speed	Plastic stick max can be 9000pcs/min Others around 800pcs/min	Plastic stick max can be 1400pcs/min Others around 1200pcs/min
Machine Size(LWH)	8.7×1×1.6	9.5×1×1.6 m
Machine Weight	1800kg	1800kg

REMARKS

Packaging method: wooden case or as your requests Loading port: Shanghai, Ningbo or as your requests Delivery time: 7-15 days for ready goods, 30 days for new Trade terms: FOB, C&F Payment terms: T/T, L/C
