Home > Products > Rolling Shutter Machine > high quality 45mm rolling shutter slat forming machine for 0.22 - 0.35mm Thickness automatic line
high quality 45mm rolling shutter slat forming machine for 0.22 - 0.35mm Thickness automatic line
Negotiable
/ Set
1 Set(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
350mm Coil Width Rolling Shutter Strip Making Machine with HRC58-62 Roller Material
-
380V 50Hz Aluminum Rolling Shutter Machinery PU inject with 37 Roller Stations
-
0.22 - 0.35mm Thickness Shutter Door Roll Forming Machine CE / ISO Approved
-
2 Tons 15-30m/min Forming Speed Rolling Shutter Machine GCr15 Steel Roller Material
-
Pneumatic Servo Flying Saw Cutting Rolling Shutter Machine , Roof Making Machine
-
11KW PLC Control System Roller Shutter Forming Machine for Shutter Door / Garage Door
Product Details
| Brand Name | HUAZHONG | Place of Origin | China | |
| Model Number | HZ-45 |
Product Description
Certification:CE/ISO
Detailed Product Description
Fast 45mm rolling shutter slat forming machine for 1.5 - 3.0mm Thickness aluminum Material
?
? Technical Procss?
Decoiling---foam--- Heat preservation---roll forming---automatic cutting---off---discharging
??Main Specifications??
|
Coil Material |
Thickness | 0.22-0.35mm |
| Coil width | Custom-made | |
| Yield Strength | 100-260Mpa | |
| Material | Aluminum ? ? ? ? ? ? ? ? ? ? ? ?? | |
| Decoiler / Uncoiler | Coil Width | Max. 350mm |
| I.D | 300mm | |
| O.D | Max. 560mm | |
| Roll Forming??Machine | Forming stations | 37 Stations ( Depend on Profiles ) ? |
| Roller material ? | GCr15 steel, HRC58-62??????????? | |
| Diameter of shaft?????????????????? | 40mm | |
| Shaft material | High grade 45# steel | |
| Drive type | Gear box with universal joint transmission system | |
| Forming speed ? ?? | 15-30m/min | |
| Main power | 11KW | |
| Cutting | Cutting type | Pneumatic servo flying saw cutting |
| Cutting?Tolerance???? | 10m0.5mm | |
| Encoder | OMRON Brand | |
| Electrical control | PLC | Delta Brand or Custom-made |
| Inverter | Delta?Brand or Custom-made | |
| Touch screen | Delta? Brand?or Custom-made | |
| Operation type | Touch screen & Button | |
| Runout Table | Table type | Simple nonpower type |
| Function | To support the finished panels |
??Main Components??
| Main Roll Forming Machine | 1 Unit |
| PLC Computer Control Board | 1 Unit ? ? ?? |
| Fast conveyor belt | 1 Unit |
| Decoiler / Uncoiler | 1 Unit |
| Cutting To Length | 1 Unit |
| Runout Table |
1 Unit |
??Application??
For shutter door Garage door
??Our Advantage??
High Quality Reasonable Price Good after Service 1 Year Warranty More Than 20 Years ExperienceMachine Pictures??
