37 Roller Station 11KW Roll Shutter Door Forming Machine Aluminum Material

37 Roller Station 11KW Roll Shutter Door Forming Machine Aluminum Material

Detailed Product Description

?Technical Process?

Decoiling---foam--- Heat preservation---roll forming---automatic cutting---off---discharging

?Main Specifications??

- Suitable raw material: Aluminum?steel sheet?
- Thickness of the material: 0.22-0.35mm?
- Diameter of roller shaft:40mm

- Roller material :?GCr15 steel, HRC58-62
- Capacity of decoiler: 2000Kgs.?
- Forming speed:15-30m/min?

- Drivr type:Gear box with universal joint transmission system
- Main motor power: 11KW (Depend on final design)?

- Shaft material: High grade 45# steel
- Controling system: Panasonic PLC & converter?
- Votage: 380V, 3 phase 50Hz (Also depond on customer\'s requirment)?
- The ]forming steps: 37?(depend on final design)?
- Machine dimension: depend on final design

Cutting?

(1)Cutting?motion:?The?main?machine?falying saw cutting?

(2)Material?of?blade:?CR12?with?heat?treatment?

(3)Length?measuring:?Automatically?

(4)Tolerance?of?length:?10m0.5mm

(5)?Cutting?way:?The?main?machine?falying saw cutting

(6) Encoder:OMRON Brand

Control?Box:?

(1)?Power?supply:?380?V,?50?Hz,?3Phase?(adjusted?with?the?requirement)

(2)?Length?&?quantity?measurement?automatically;

(3)?Length?&?quantity?controlled?by?PLC,

(4)?Length?inaccuracy?can?be?amended?easily.?

(6).Control?panel:?Button-type?switch?and?touch?screen

(7)?Unit?of?length:?millimeter?(switched?on?the?control?panel)

?Main Components??

??Application??

For shutter door Garage door

?Our Advantage??

Machine Pictures??
