Samsung S3C2440 ARM9 Board mini2440 1GB

Samsung S3C2440 ARM9 Board mini2440 1GB

Specification:
RoHS Compliant
Dimension: 100 x 100 mm
CPU: 400 MHz Samsung S3C2440A ARM920T (Max freq. 533 MHz)
RAM: 64 MB SDRAM, 32 bit 100 MHz Bus
Flash: 1GB NAND Flash and 2 MB NOR Flash with BIOS
EEPROM: 1024 Byte 24C08 (I2C)
Ext. Memory: SD-Card socket
Serial Ports: 1x DB9 connector (RS232), total: 3x serial ports on the PCB
USB: 1x USB-A Host, 1x USB-B Device
Audio Output: 3.5 mm stereo jack
Audio Input: on PCB + condenser microphone
Ethernet: RJ-45 10/100M (DM9000)
RTC: Real Time Clock with battery
Beeper: PWM buzzer
Camera: 20 pin Camera interface
LCD Interface
STN Displays
TFT Displays
Connector for FriendlyARM Displays (3,5" and 7") and VGA Board
Touch Panel: 4 wire resistive

User Inputs: 6x push buttons and 1x A/D pot
User Outputs: 4x LEDs
Expansion: 40 pin System Bus, 34 pin GPIO (2.0mm)
Debug: 10 pin JTAG (2.0mm)
Power: 5V connector, power switch and LED
Power Supply: regulated 5V
OS Support: Android, Linux 2.6, Windows CE 5 and 6

Package contains:
Mini2440
USB A-B Cable
RJ45 Cable
Serial Cable
LPT - JTAG Adapter
Pen for Touch Panel
DVD
