Low Power Water Treatment Sodium Hypochlorite Solution For Disinfection

Low Power Water Treatment Sodium Hypochlorite Solution For Disinfection

Technical parameters:

Product feature :

Chlorine concentration brine? :2.5%

Power consumption : less than 3.5KW/ kg

Content available CL :7000~9000ppm

Working way : Unattended , fully automatic operation

Life expectancy of anode coating : more than 5 years, and anode coating can be coated and used repeatedly

Life expectancy of the electrode plates:more than 20 years??????????

Life expectancy of whole machine : more than 15 years

Product introduce:

1,Generation principle?:

CNJY – R series NaClO generator is a new type of NaClO solution for field production equipment , suitable for all kinds of needs NaClO disinfected venues . Its working principle is: the sodium chloride solution under the certain cell voltage function, in a series of electrochemical reaction occurs in the cell , the resulting NaClO solution , including the generation of NaClO through chemical equation can be expressed as follows :

The electrode reaction:

anode:2Cl--2e→Cl2

cathode:2H++2e→H2

solution:2NaOH+Cl2→NaCl+NaClO+H2O

Work flow chart :

Product system :

Preparation of brine , ?and filtering

Mainly includes concentrated brine tank , dilute brine tank , pump, secondary PP material , 5 um level precision filter, salt can be completely filtering impurities.

Storage and dosing system

Mainly includes storage tank, hydrogen detector, dosing pump, on-line monitoring, etc.

Electrode part

Mainly includes the electrode slice ,terminal and the protector.

Power part

Mainly includes the high frequency power switch and controller.
