5.8GHz ISM band 200w DC Motion Sensor , Wide Detection Area 16 Meter

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Merrytek		Place of Origin	China
Model Number	MC011D5

Product Description

Delivery Time:1, Sample and small order: Within 5 working days 2, Bulk order: within 3-4 weeks
Certification:CE , R&TTE

5.8GHz ISM band DC input Microwave motion sensor MC011D5 with dimming function, CE & R&TTE

Description

? 200w DC operation Microwave motion sensor ? Gradually dimming design ? Wide detection area, range up to 16m in diameter ? Support on off and 3 step dimming function ? Max operating current 2A max ? Economic solution to achieve dimming function ? No need dimmable led driver, simple constant current led driver is comparable ? Easy installation, workable for ceiling lamp, tri-proof light. ? Automatic switching based on motion and ambient light level. ? 4-pole press-in terminal (L, N, N, L′), easy assembly. ? Sensor data can be simply set via DIP switch. ? The sensor provides a simple and cost-effective dimming solution. With DC operation voltage from LED driver, no need extra power from line. Without DALI or 1-10V dimmable LED divers, they are suitable for most common LED drivers and achieve 2-step dimming function. Particularly suitable for price sensitive luminaries.

On-off function?

2- Step dimming function

Specifications:

Operating voltage	25 ~ 100Vdc
Rated load	Max.200wLED light
HF system	5.8GHz±75MHz, ISM wave band
Operating current	2A max
Power consumption	≤0.5W(standby), <1W(operation)
Transmitting power	<0.5mW
Detection zone Max.(D x H)	16m x 6m
Motion detection	0.5~3m/s
Detection angle	150°(wall installation) 360°(ceiling installation)
IP rating	IP20
Operation Temperature	-20℃~50℃
Hold time	10s/1min/3min/10min
Detection sensitivity	10% / 50% / 75% / 100%
Dimming level	10％/20% / 30% / 40% / 50％/ 60% / 70％/80％
Dimming mode	Step dimming
Daylight Sensor	10lux / 30lux / 50lux /Disable
Stand-by period	0s / 5min / 10min / 30min /100min / +∞
Life time	50000 hours
Guaranty	5 years

Applications:

Stairwell, Corridor, Balcony, Pathway, etc.
