SUNBOW UL Approval ID 10MM Silicone Fiberglass Sleeving White Black Red for Insulators
- T/T L/C D/P D/A
- 7 days
You May Like
-
Chemical and Corrosion Resistant Transparent FEP Tubing with Smooth Surface
-
Black White Red Custom Silicone Fiberglass Sleeving for Joint Insulating 4000V 4KV
-
Insulation Protective Silicone Fiberglass Sleeving / Rubber Coated Fiber-glass Sleeve
-
Colorful Silicone Rubber Fiberglass Sleeving / Braided Fiber Glass insulation Sleeve
-
Electric Wires Varnished Silicone Fiberglass Sleeving / Fiber Glass Insulation Sleeve
-
Fireproof Outer Silica Inner Silicone Fiberglass Sleeving for Wire Insulating 0.5mm ~ 30.0mm
Product Details
| Brand Name | Sunbow | Place of Origin | China | |
| Model Number | SB-SGS-40 |
Product Description
Certification:UL , RoHS , Reach , CSA
SUNBOW UL Approval ID 10MM Silicone Fiberglasss Sleeving White
1. Model Number: SB-SGS-40
Working temperature: 200oC
2. Structure
SUNBOW UL Approval ID 10MM Silicone Fiberglasss Sleeving White?is non-alkali fiberglass braided then coated with silicone resin and treated in high temperature.
3. Specification
|
Item |
Performance |
Note |
|
|
Dielectric Breakdown??? Voltage? KV? AC |
Minimum Average |
≥4.0 |
Before Aging |
|
Minimum Single Point |
≥3.0 |
||
|
Minimum Average |
≥3.0 |
6 Hrs* 245±5oC 245±5oC 6Hrs Aging |
|
|
Minimum Single Point |
≥2.0 |
||
|
Thermal Endurance |
No Indication of Crack |
OK |
6 Hrs* 245±5oC 245±5oC 6Hrs Aging |
|
Fire Resistance |
VW-1 |
OK |
UL 1441 |
4. Usage
SB-SGS-40?sleeving with its good dielectric strength, flexibility and flame retarding properties make it high performance qualities. It can be widely used in insulated or partially insulated conductors, bus bars, component leads, or assemblies of electrical components etc.
5. Dimension
|
Inside Diameter |
Wall Thickness (mm) |
Standard Package??????? (m/roll) |
|
|
Nominal(mm) |
Tolerance(mm) |
||
|
φ0.5 |
+0.2, -0.1 |
≥0.37 |
200 |
|
φ1.0 |
+0.2, -0.1 |
≥0.37 |
200 |
|
φ1.5 |
+0.2, -0.1 |
≥0.37 |
200 |
|
φ2.0 |
+0.2, -0.1 |
≥0.37 |
200 |
|
φ2.5 |
+0.3, -0.1 |
≥0.42 |
200 |
|
φ3.0 |
+0.3, -0.1 |
≥0.42 |
200 |
|
φ4.0 |
+0.3, -0.1 |
≥0.42 |
200 |
|
φ4.5 |
+0.3, -0.1 |
≥0.51 |
100 |
|
φ5.0 |
+0.3, -0.1 |
≥0.51 |
100 |
|
φ6.0 |
+0.3, -0.1 |
≥0.51 |
100 |
|
φ7.0 |
+0.3, -0.1 |
≥0.56 |
100 |
|
φ8.0 |
+0.3, -0.1 |
≥0.56 |
100 |
|
φ9.0 |
+0.3, -0.1 |
≥0.66 |
100 |
|
φ10.0 |
+0.3, -0.1 |
≥0.66 |
100 |
|
φ12.0 |
+1.0, -1.0 |
≥0.66 |
50 |
|
φ14.0 |
+1.0, -1.0 |
≥0.66 |
50 |
|
φ16.0 |
+1.0, -1.0 |
≥0.66 |
50 |
|
φ18.0 |
+1.0, -1.0 |
≥0.66 |
50 |
|
φ20.0 |
+1.0, -1.0 |
≥0.76 |
25 |
|
φ25.0 |
+1.0, -1.0 |
≥0.76 |
25 |
