Home > Products > Silicone Fiberglass Sleeving > Silicone Coated Fiberglass Braided Sleeving / Insulation Silicon Glass Tube Cable Sleeve
Silicone Coated Fiberglass Braided Sleeving / Insulation Silicon Glass Tube Cable Sleeve
- T/T L/C D/P D/A
- 7 days
You May Like
-
Eco-friendly Rubber Silicone Fiberglass Sleeves Multi Color for Customized 0.5mm ~ 30.0mm
-
Electric Wires Varnished Silicone Fiberglass Sleeving High Temperature Resistant
-
Wire Insulating Rubber Silicone Coated Fiberglass Sleeving with UL RoHS Approval
-
7KV Insulation Fiberglass Sleeve with Silicone Coating 2.0mm ID 200C High Temperature
-
Aolvent Resistant Clear Plastic Tubing PVDF Heat Shrink Tube for Cable and Wire Insulation
-
Flexible Clear Plastic Tubing PVDF Heat Shrinkable Tube / Pipes / Sleeving 175C
Product Details
| Brand Name | Sunbow | Place of Origin | China | |
| Model Number | SB-SGS-15 |
Product Description
Certification:UL , RoHS , Reach , CSA
Fiberglass Electric Insulation Sleeve Silicone Glass Tube Cable Sleeving
1. Model Number: SB-SGS-15
2. Product Structure
Fiberglass Electric Insulation Sleeve Silicone Glass Tube Cable Sleeving?is non-alkali fiberglass braided then coated with silicone resin and treated in high temperature.
3. Working temperature: 200oC
4. Specification
|
Item |
Performance |
Note |
|
|
Dielectric Breakdown Voltage?? KV? AC |
Minimum Average |
≥1.5 |
Before Aging? |
|
Minimum Single Point |
≥1.0 |
||
|
Minimum Average |
≥1.0 |
6 Hrs* 245±5oC 245±5oC 6Hrs Aging |
|
|
Minimum Single Point |
≥0.7 |
||
|
Thermal Endurance |
No Indication of Crack |
OK |
6 Hrs* 245±5oC 245±5oC 6Hrs Aging |
|
Fire Resistance |
VW-1 |
OK |
UL 1441 |
5. Dimension
|
Inside Diameter? |
Wall Thickness ?(mm) |
Standard Package ???????? (m/roll) |
|
|
Nominal(mm) |
Tolerance(mm) |
||
|
φ0.5 |
+0.2, -0.1 |
≥0.30 |
200 |
|
φ1.0 |
+0.2, -0.1 |
≥0.30 |
200 |
|
φ1.5 |
+0.2, -0.1 |
≥0.30 |
200 |
|
φ2.0 |
+0.2, -0.1 |
≥0.30 |
200 |
|
φ2.5 |
+0.3, -0.1 |
≥0.35 |
200 |
|
φ3.0 |
+0.3, -0.1 |
≥0.35 |
200 |
|
φ4.0 |
+0.3, -0.1 |
≥0.35 |
200 |
|
φ4.5 |
+0.3, -0.1 |
≥0.40 |
100 |
|
φ5.0 |
+0.3, -0.1 |
≥0.40 |
100 |
|
φ6.0 |
+0.3, -0.1 |
≥0.40 |
100 |
|
φ7.0 |
+0.3, -0.1 |
≥0.45 |
100 |
|
φ8.0 |
+0.3, -0.1 |
≥0.45 |
100 |
|
φ9.0 |
+0.3, -0.1 |
≥0.55 |
100 |
|
φ10.0 |
+0.3, -0.1 |
≥0.55 |
100 |
|
φ12.0 |
+1.0, -1.0 |
≥0.55 |
50 |
|
φ14.0 |
+1.0, -1.0 |
≥0.55 |
50 |
|
φ16.0 |
+1.0, -1.0 |
≥0.55 |
50 |
|
φ18.0 |
+1.0, -1.0 |
≥0.55 |
50 |
|
φ20.0 |
+1.0, -1.0 |
≥0.65 |
25 |
|
φ25.0 |
+1.0, -1.0 |
≥0.65 |
25 |
|
φ30.0 |
+1.0, -1.0 |
≥0.65 |
25 |
6. Usage
SB-SGS-15?sleeving with its good dielectric streng
