4KV Braided Silicone Coated Fiberglass Sleeve for Home Electrical Appliance
- T/T L/C D/P D/A
- 7 days
You May Like
-
SUNBOW UL Approval ID 10MM Silicone Fiberglass Sleeving White Black Red for Insulators
-
Chemical and Corrosion Resistant Transparent FEP Tubing with Smooth Surface
-
Black White Red Custom Silicone Fiberglass Sleeving for Joint Insulating 4000V 4KV
-
Insulation Protective Silicone Fiberglass Sleeving / Rubber Coated Fiber-glass Sleeve
-
Colorful Silicone Rubber Fiberglass Sleeving / Braided Fiber Glass insulation Sleeve
-
Electric Wires Varnished Silicone Fiberglass Sleeving / Fiber Glass Insulation Sleeve
Product Details
| Brand Name | Sunbow | Place of Origin | China | |
| Model Number | SB-SGS-40 |
Product Description
Certification:UL , RoHS , Reach , CSA
4KV Red Silicone Fiberglasss Sleeving for Home Electrical Appliance
1. Product Information
4KV Red Silicone Fiberglasss Sleeving for Home Electrical Appliance?is non-alkali fiberglass braided then coated with silicone resin and treated in high temperature.
2. Model Number: SB-SGS-40
Working temperature: 200oC
3. Specification
|
Item |
Performance |
Note |
|
|
Dielectric Breakdown??? Voltage? KV? AC |
Minimum Average |
≥4.0 |
Before Aging |
|
Minimum Single Point |
≥3.0 |
||
|
Minimum Average |
≥3.0 |
6 Hrs* 245±5oC 245±5oC 6Hrs Aging |
|
|
Minimum Single Point |
≥2.0 |
||
|
Thermal Endurance |
No Indication of Crack |
OK |
6 Hrs* 245±5oC 245±5oC 6Hrs Aging |
|
Fire Resistance |
VW-1 |
OK |
UL 1441 |
4. Dimension
|
Inside Diameter |
Wall Thickness (mm) |
Standard Package??????? (m/roll) |
|
|
Nominal(mm) |
Tolerance(mm) |
||
|
φ0.5 |
+0.2, -0.1 |
≥0.37 |
200 |
|
φ1.0 |
+0.2, -0.1 |
≥0.37 |
200 |
|
φ1.5 |
+0.2, -0.1 |
≥0.37 |
200 |
|
φ2.0 |
+0.2, -0.1 |
≥0.37 |
200 |
|
φ2.5 |
+0.3, -0.1 |
≥0.42 |
200 |
|
φ3.0 |
+0.3, -0.1 |
≥0.42 |
200 |
|
φ4.0 |
+0.3, -0.1 |
≥0.42 |
200 |
|
φ4.5 |
+0.3, -0.1 |
≥0.51 |
100 |
|
φ5.0 |
+0.3, -0.1 |
≥0.51 |
100 |
|
φ6.0 |
+0.3, -0.1 |
≥0.51 |
100 |
|
φ7.0 |
+0.3, -0.1 |
≥0.56 |
100 |
|
φ8.0 |
+0.3, -0.1 |
≥0.56 |
100 |
|
φ9.0 |
+0.3, -0.1 |
≥0.66 |
100 |
|
φ10.0 |
+0.3, -0.1 |
≥0.66 |
100 |
|
φ12.0 |
+1.0, -1.0 |
≥0.66 |
50 |
|
φ14.0 |
+1.0, -1.0 |
≥0.66 |
50 |
|
φ16.0 |
+1.0, -1.0 |
≥0.66 |
50 |
|
φ18.0 |
+1.0, -1.0 |
≥0.66 |
50 |
|
φ20.0 |
+1.0, -1.0 |
≥0.76 |
25 |
|
φ25.0 |
+1.0, -1.0 |
≥0.76 |
25 |
|
φ30.0 |
+1.0, -1.0 |
≥0.76 |
25 |
5. Usage
SB-SGS-40?sleeving with its good dielectric strength, flexibility and flame retardin
