Ceiling Mount Wireless Motion Sensor1200W With 5.8GHz75MHz , ISM Wave Band

Brand Name	Merrytek		Place of Origin	China
Model Number	MC003V/CP+MW01

Delivery Time:1, Sample and small order: Within 5 working days 2, Bulk order: within 3-4 weeks
Certification:CE , R&TTE

RF Wireless Networking Microwave Motion Sensor MC003V/CP+MW01, Clustered control

Description:

??Used in wireless networking of luminaries, easy installation and free of wire. ? With fixed code, very easy to step up any-to-any communication. ? By digital receiving and transmitting method, high anti-interference capability and no interference to an RF sensitive device, for example, electronic keys of cars. ? With advanced code detection technology, no code missing. ? Merrytek takes the lead in using the rotary coding switch in RF transceiver, very easy to create groups. ? MC003V/CP is an active motion detector with HF system 5.8GHz. Motion can be detected through plastic, glass and thin non-metal materials. ? MW01 is an innovative and unique wireless transceiver with frequency range 433MHz. Due to use full digital receiving& transmitting and fixed address code for creation of groups, it has high reliability and stability. ? The RF module integrates advanced code check technology, significantly improved transmission reliability. Make sure exact signal transmitting and receiving, no code missing. ? Merrytek takes the lead in adopting the rotary coding switch to set up groups, very simple to achieve any-to-any communication.

Specifications:

MC003V/CP:

Operating voltage	220-240Vac, 50/60Hz
Rated load	800W (inductive), 1200W(resistive)
HF system	5.8GHz±75MHz, ISM wave band
Power consumption	≤0.5W(standby), <1W(operation)
Transmitting power	<0.5mW
Detection zone Max.(D x H)	16m x 10m
Motion detection	0.5~3m/s
Detection angle	150°(wall installation) 360°(ceiling installation)
IP rating	IP20
Operation Temperature	-35℃~70℃
Hold time	10s/30s/90s/3min/20min/30min
Detection sensitivity	10％/25%/50％/75％/100％
Daylight sensor	5lux / 10lux / 30lux / 50lux / Disable
Stand-by dimming level	10％/20％/30％/50％
Stand-by period	5s/5min/10min/30min/1h/Disable
Life time	50,000 hours
Guaranty	5 years

MW01:

Operating voltage	12VDC
Transmitting power	≤20mW
Frequency range	433MHz
Standby-power	<0.3W
Operating principle	Radio transmission
Transmission distance	Max:100m in the free field Max:30m inside buildings
Operating temperature	-20℃~70℃
IP rating	IP20

Applications:

Stairwell, Corridor, Balcony, Pathway, Warehouse, etc
