Home > Products > Metal Engraving Machine > JK-3030 4 Axis Metal Engraving Machine

JK-3030 4 Axis Metal Engraving Machine

FOB Price

Negotiable / Case

1 Case(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Jingke		Place of Origin	China
Model Number	JK-3030

JK-3030 4 axis metal engraving machine:

Machine features of JK-3030 4 axis metal engraving machine:

1. Particular style, competent for elaborate engraving and cutting various material.

2. 800W water-cooled spindle motor.

3. The lathe bed is wholly cast with iron to ensure high stability. Three axes all adopt linear square rail.

4. Furnish with DSP control system if you need.

5. Be compatible with type 3, Artcut, Artcam software.

6.Memory to ensure the processing point when the blade is broken or postpone stitution. Specific saving mode of different points.

Technical parameter:

modle	JK-3030
Work dimensions	300×300mm
Body dimensions	600×600×600mm
Z-axis working area	45 or 60mm
Max feeding height	100mm or bigger
Cut thickness of material	≤30mm
Max.speed	6000mm/min
Working speed	0-4000mm/min
Mechanical precision	0.01mm
Software	type3,Artcut,Artcam software
Power	1500W
Working voltage	AC 220V/50Hz
Drive type	stepper motor
Spindle	800W variable speed,water-cooled
Spindle speed	0-24,000rpm
Blade diameter	1-6mm
Control system	NCSTUDIO
Command	HPGL.G code,u00,mmg,plt
Rotary	With rotary device
