Bottling machine liquid milk

Bottling machine liquid milk

 Characteristic:

1,The all machine applies bottle handling technical and the filling valves go up-down when filling, which make sure the bottle filling goes stable, reliable during high speed. The bottle handling technical also make the different bottle changing easily without changing too many accessories.

2, This machine uses new generation stainless steel spring washing clips and the clips do not contact the upside of bottle screw avoiding the second pollution. It can both clear the inside and the outside of the bottle.

3, The advanced normal pressure filling principle was applied. Filling is quick, and stable. Not contacting with the liquid avoids second pollution and oxidation.

4, This machine applies magnetic force screw type sealing, realizing auto grasping cap, sealing. The sealing cap force can be adjusted.

5, Independent electricity box makes sure every electrical appliance works normally.

Disposition :

1,Motor: SIEMENS BEIDE

2,Speed reducer: JIE brand Hangzhou

3,Invert speed control: Japanese Mitsubishi

4,PLC: Japanese Mitsubishi

5,Touch screen: TAIWAN WEINVIEW

6,Electricity appliance: SIEMENS

7, Volume of PET bottle : 0.25L-2L

8,Filling temperature: Hot filling

9,Filling precision: ±2-3%

10,Pressure of washing: 0.2Mpa

11,Washing consuming clear water:800kg/h

12,Power of main motor: 4.2 KW

13,Dimension: 2950×2300×2250mm

14,Weight: 4500kg
