Clip Lock Profile Roof Panel Roll Forming Machine with 1.0 mm Zinc and Color Steel

Clip Lock Profile Roof Panel Roll Forming Machine with 1.0 mm Zinc and Color Steel

Technological Process

De?coiler—feeding—guide---roll?forming----cut?to?length—Out?table

Description of?Clip Lock Profile Roof Panel Roll Forming Machine

Composition?of?machine

Roll?forming?main?machine……………………………1?unit

Manual?Un?coiler………………………………………?1?unit

Control?panel…………………………………………..1?unit

Hydraulic?station……………………………………?…1?unit

Manual?out?table………………………?……………….2?unit

Specifications?of?Clip Lock Profile Roof Panel Roll Forming Machine

1:?Coil?width:?depend?on?your?profiles?

2:?working?speed:?12-15m/min?(not?contain?cutting)

3:?roll?station:?about?16-24stations

4:?material?of?roller:?grade?45?steel,?polished?and?coated?with?chrome?

5: material?of?main?shaft:45﹟?steel???diameter?roller:?Ф70mm

6:?main?power:?7.5KW???

7:?forming?thickness:?1.0mm?zinc?and?color?steel,?250Mpa-G550MPA

8:?Transmission:?by?single?Chains?1.5inch?

9:?feeding?and?guide:?surface?polished?and?coated?with?chrome

10:?machine?drive?parts?adopt?protect?cover?

11:?machine?adopt?new?station?with?chrome?

12:?size?of?main?machine:?7500x1500x1300(mm)???L?x?W?x?H?need?1x40GP?container

13:?weight:?about?6000Kgs

14:?color?of?machine:?blue?(also?can?choose?by?customer?request)

15:?machine?should?be?with?four?legs?(made?from?metal)?in?350mm

Quick?Detail

We?are?Specialists?in?roll?forming?machines?for?the?manufacture?the?production?of?building?construction,?such?as?for?the?metal?roofing?and?wall,?various?trapezoidal?profiles?can?be?custom?manufactured.?We?build?complete?roll?forming?lines?for?roofing?&?cladding?lines.

Metal?(including?steel?and?aluminum)?usage?in?construction?is?increasing?more?than?any?other?building?product?out?there.?Steel?roofing?and?steel?walls?are?all?manufactured?on?roll?formers.?Rollforming?is?a?process?by?which?a?flat?coil?of?steel?is?fed?through?rolls?and?formed?to?make?a?finished?product.?

We?are?one?of?the?leading?suppliers?and?manufacturer?in?china?and?have?been?supplying?and?making?roll?forming?equipment?for?the?metal?building?construction?industry?for?a?long?time.

Our?roof?panel?roll?forming?machines?are?special?for?manufacturing?high?quality?steel?roof?&?wall?cladding?panels,?aluminum?Lock?Roofs.?With?our?engineer’s?many?times?improvements,?the?Ribbed?Roof?Panels?machine?design?is?perfect.?The?Ribbed?Roof?profile?surface?is?smooth?and?power?fee?is?lower,?driven?by?chain.

It?is?specially?designed?forming?roofing?corrugated?sheet,?wall?panel,floor?deck,?under?mass-production.?The?highest?speed?of?the?line?can?reach?to?30?M/min?working?with?fully?automaticlly?stacking?system.

Competitive?Advantage

One?roll?forming?machine?only?can?produce?one?profile.
We?can?manufacture?as?per?customer?provided?drawings?with?specification?or?real?objects?of?sectional?materials,?custom?roll?forming?machine?is?welcome.

The?following?is?some?corrugated?panel?roofs?profiles?for?your?reference.

More?information?about?steel?roof?panel?profiles,?Pls?contact?with?us!
