Aluminum IBR Roof Panel / Wall Profile Roll Forming Machine with 70 mm Diameter Roller

Specifications of?Aluminum IBR Roof Panel / Wall Profile Roll Forming Machine

1:?Coil?width:?depend?on?your?profiles?

2: Working?speed:?12-15m/min?(not?contain?cutting)

3: Roll?station:?about?16-24stations

4: Material?of?roller:?grade?45?steel,?polished?and?coated?with?chrome?

5: Material?of?main?shaft:45﹟?steel???diameter?roller:?Ф70mm

6: Main?power:?7.5KW???

7: Forming?thickness:?1.0mm?zinc?and?color?steel,?250Mpa-G550MPA

8:?Transmission:?by?single?Chains?1.5inch?

9: Feeding?and?guide:?surface?polished?and?coated?with?chrome

10: Machine?drive?parts?adopt?protect?cover?

11: Machine?adopt?new?station?with?chrome?

12: Size?of?main?machine:?7500x1500x1300(mm)???L?x?W?x?H?need?1x40GP?container

13: Weight:?about 8000Kgs

14: Color?of?machine:?blue?(also?can?choose?by?customer?request)

15: Machine?should?be?with?four?legs?(made?from?metal)?in?350mm

Quick?Detail

We?are?one?of?the?leading?suppliers?and?manufacturer?in?china?and?have?been?supplying?and?making?roll?forming?equipment?for?the?metal?building?construction?industry?for?a?long?time.

We?are?Specialists?in?roll?forming?machines?for?the?manufacture?the?production?of?building?construction,?suchas?for?the?metal?roofing?and?wall,?various?trapezoidal?profiles?can?be?custom?manufactured.?We?build?complete?roll?forming?lines?for?roofing?&?cladding?lines.

Metal?(including?steel?and?aluminum)?usage?in?construction?is?increasing?more?than?any?other?building?product?out?there.?Steel?roofing?and?steel?walls?are?all?manufactured?on?roll?formers.?Rollforming?is?a?process?by?

which?a?flat?coil?of?steel?is?fed?through?rolls?and?formed?to?make?a?finished?product.?

Our?roof?panel?roll?forming?machines?are?special?for?manufacturing?high?quality?steel?roof?&?wall?cladding?

panels,?aluminum?Lock?Roofs.?With?our?engineer’s?many?times?improvements,?the?Ribbed?Roof?Panels?

machine?design?is?perfect.?The?Ribbed?Roof?profile?surface?is?smooth?and?power?fee?is?lower,?driven?by?

chain.

It?is?specially?designed?forming?roofing?corrugated?sheet,?wall?panel,floor?deck,?under?mass-production.?The?highest?speed?of?the?line?can?reach?to?30?M/min?working?with?fully?automaticlly?stacking?

system.

Composition?of?Aluminum IBR Roof Panel / Wall Profile Roll Forming Machine

Roll?forming?main?machine……………………………1?unit

Manual?Un?coiler………………………………………?1?unit

Control?panel…………………………………………..1?unit

Hydraulic?station……………………………………?…1?unit

Manual?out?table………………………?……………….2?unit

Competitive?Advantage

One?roll?forming?machine?only?can?produce?one?profile.
We?can?manufacture?as?per?customer?provided?drawings?with?specification?or?real?objects?of?sectional?materials,?custom?roll?forming?machine?is?welcome.?The?following?is?some?corrugated?panel?roofs?profiles?for?your?

reference.

More?information?about?steel?roof?panel?profiles,?Pls?contact?with?us!
