Home > Products > shot blasting machine > Deck Waterproof Ptretreatment Rust Peeling Shot Blaster
Deck Waterproof Ptretreatment Rust Peeling Shot Blaster
USD $20000 - $20000
/ Piece
1 Piece(Min.Order)
- 100 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Hardwares Turntable Corrosion Prevention Pretreatment Shot Blaster
-
Small Castings Rust Peeling Shot Blaster
-
Crawler Shot Blasting Machine with Auto Loader
-
Steel Pipe Outer Surface Rust Removing Shot Blasting Equipment
-
Medium Metal Parts Rust Peeling Shot Blaster
-
Foundry Rust Peeling Shot Blasting Cabinet
Product Details
| Brand Name | ROVAN | Place of Origin | China | |
| Model Number | Q69 |
Product Description
Q69 series Deck Waterproof Ptretreatment Rust Peeling Shot Blaster is mainly composed of such stage as preheating,shot blast cleaning,painting and stove,ect. It is suitable for the surface derusting&painting craft for steel plates and sections in such industries as shipmaking, automobile making,locomtive vehicle,bridge and machinery .
Deck Waterproof Ptretreatment Rust Peeling Shot Blaster Technical parameters
Type | Q698 | Q6912 | Q6915 |
Effective cleaning width(mm) | 800 | 1200 | 1500 |
Dimension of intel opening(mm) | 800*1600 | 1200*400 | 1500*400 |
Length of cleaning piece(mm) | 1200-12000 | 1200-6000 | 1200-12000 |
Roller speed(stepless speed regulation)(m/min) | 0.5-4 | 0.5-4 | 0.5-5 |
Thickness of cleaning steel plate(mm) | 3-60 | 3-60 | 1.5-60 |
Specification of the threated sectional bars | Φ16-28 | 1≤20#<≤16# | 1≤20#<≤16# |
Abrasive flow rate(kg/min) | 8*120 | 4*250 | 4*250 |
Abrasive initial filling(kg) | 4000 | 4000 | 4000 |
Adjusting height of rolling brush(scraping plate)(mm) | 4000 | 200 | 350 |
Ventilation capacity(m3/h) | 22000 | 17560 | 19000 |
Outline dimensions(mm) | 25017*4500*9015 | 12180*4250*7095 | 15200*5370*6797 |
Pit depty(mm) | 1937 | 1616 | 2257 |
Total power(excluding dedusting)(kw) | 90 | 78.3 | 113.5 |
Gross weight of machine(t) | 20 | 20.4 | 33 |
Type | Q6920 | Q6925 | Q6930 | Q6940 |
Effective cleaning width(mm) | 2000 | 2500 | 3000 | 4000 |
Dimension of intel opening(mm) | 2000*400 | 2500*800 | 3000*800 | 4000*400 |
Length of cleaning piece(mm) | 1200-12000 | 3000-12000 | 2400-12000 | 4500-18000 |
Roller speed(stepless speed regulation)(m/min) | 0.5-4 | 0.5-4.5 | 0.5-4 | 2-8 |
Thickness of cleaning steel plate(mm) | 3-60 | 3-60 | 3-110 | 4.5-100 |
Specification of the threated sectional bars | 1≤20#<≤16# | 60*8-300*1000 | 60*8-300*1000 | 60*8-300*1000 |
Abrasive flow rate(kg/min) | 6*250 | 6*250 | 6*360 | 8*360 |
Abrasive initial filling(kg) | 4500 | 4500 | 8000 | 11000 |
Adjusting height of rolling brush(scraping plate)(mm) | 450 | 600 | 850 | 900 |
Ventilation capacity(m3/h) | 19550 | 22758 | 28050 | 38000 |
Outline dimensions(mm) | 30650*6850*9095 | 31200*8070*7500 | 44042*6385*7758 | 45000*7830*11117 |
Pit depty(mm) | 2800 | 2353 | 2800 | 4317 |
Total power (excluding dedusting)(kw) | 156.6 | 224.55 | 204.8 | 293.6 |
Gross weight of machine(t) | 41 | 53.2 | 71.8 | 75 |
