SN3024 - SN3038 / SSN3024 - SSN3038 Plummer Block Bearing / Ball Bearing Pillow Block

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Miru ,OEM And So On		Place of Origin	China
Model Number	SN3024 - SN3038

Product Description

Delivery Time:45 DAYS
Certification:ISO9001

Reasonable Price Plummer Block Bearing SN3024 - SN3038 / SSN3024 - SSN3038
Pillow Block Bearing
Pillow Block Bearing is the rolling bearing and bearing seat together.Most particularly the spherical bearing are?made spherical outer diameter, and the imported bearing with spherical inner hole to install together, variety?structure, good versatility and interchangeability.

Split Plummer block, whose cap and base can be separated, mainly bear radial load. It fits for self-aligning spherical roller bearings or self-aligning spherical ball bearing. They are used in metallurgy, mining, conveyor systems, environment protecting and other industry. The main model No is SN series,SD series,SNU series,SNL series,1500,1600 series,Z2500Y,Z2600Y series,GZ2,GZ4 series and so on. The main difference is load and seal type (oil felt, TG, U-lock, TS ). They has good heat conduction, and also can simplify mounting and dismounting procedures, improve sealing efficiency etc.

Plain Bearing Block Housings are made up of cap, base ,aluminum bronze bushing and installing bolts, which mainly bear radial load. They needn’t to be matched with bearings, so very easy in application. There is one oil groove in the bronze bushing, where lubricant can flow into the axis from the oil hole on the cap of housings. They are mainly used in metallurgy and conveyor systems. The main model No is H2000,H4000,ZHC4-00,HX000,HZ000,ZHC2-00,XHC4-00.

Insert ball bearing units is composed of outer spherical ball bearing and pillow block. In application, it doesn’t need bearing housing., dimension is small and structure is simple, which is easy for use. The insert ball bearing units is solid type, which is rigid and can change with other types. They are able to compensate for initial errors of alignment. Besides, they are sealed at both sides, which can be used in agricultural machinery, construction equipment, conveyor systems, textile machines and fans as well as in machines for food and beverage processing and packaging.

Adapter sleeves are the most commonly used components for locating bearings with a tapered bore onto a cylindrical seating as they can be used on smooth or stepped shafts.

Application
Mechanical equipment, hydropower, construction, railway, automobile, steel, electric power, textile, packaging, medical treatment, metallurgy, mining, petroleum, electric power, papermaking, computers, electrical machinery, sports equipment, office equipment, instruments and meters, automobile motor, precision instruments, etc
?
They are easy to mount and require no additional location on the shaft. They are made up of sleeve, lock nut and lock washer. The main model No is H series, HE series, HS series, HA series and OH series.

Split plummer block housing is generally used for self-aligning ball bearings, barrel roller bearings and spherical roller bearings. With the advantage of tight-construction, easy assembly and disassembly and wide range of self-alignment, it was widely used for agricultural equipment, food processing and conveyer system.
?
1. ?We can change the rubber seal color according to your actual requirements.
?2. Customized the marks based on your requirements.
?3. Choose the different package to your needs.

SN500(SSN500)?SN600(SSN600)?SN200?SN300?SNU500?S3000K?SD3000?SD3100?SD500

SD600?SN3000(SSN3000)?SN3100(SSN3100)?1500?1200?722500?SAF500?SAF600

Housing No.	Shaft? dia d1	Dimensions(mm)	Hou- sing Wt (kg)
D H8	a	b	c	g H12	h h12	L	W	m	n	u	v	f1 H13	f2	S	d2 H12	d3 H12
(2)	(4)
SN3024	SSN3024	110	180	380	110	40	56	112	160	218	320	60	26	32	8	10.7	M24	M16	113	135	17
SN3026	SSN3026	115	200	410	120	45	62	125	175	240	350	70	26	32	8	10.7	M24	M16	118	140	20
SN3028	SSN3028	125	210	410	120	45	63
