Casting Vertical Mounted Ball Bearing Pillow Block UCPH204 - UCPH212 100Cr6

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	miru		Place of Origin	China
Model Number	UCPH204 - UCPH212

Product Description

Delivery Time:45 DAYS
Certification:ISO9001

Vertical Mounted Ball Bearings ?UCPH204 - UCPH212 100Cr6 Long Life , Casting

Types available: UCP series, UCF series,?UCFL series,?UCT series, UCFC series, UCFS series, UCPA?series,UCFA series, UCFB?series, UCPX series, UCFX series?UCPH series

?1) Radial insert ball bearings are particularly easy to fit. They are located on the shaft by means of an eccentric locking collar, grub screws in the inner ring, an adapter sleeve, drive slot or fit.
?2) The radial insert ball bearings are integrated in the housing units. In order to ensure correct function and operational reliability in all operating conditions, the bearing and housing are matched to each other.
?3) Housing materials: cast iron pillow blocks / cast iron plummer blocks / sheet steel housings / plastic housings / stainless steel housings.

Competitive Advantage:
?
??1) Excellent and high quality control
? 2) Fast delivery
? 3) Competitive price
? 4) Small order accepted
? 5) Customers\' drawing or samples accepted
? 6) Less vibration and noise
? 7) Large Inventories

Specifications of pillow block bearing UCPH206 PH206

Item NO.	UCPH206 PH206
Bearing type	Pillow block bearing
Size(mm)	16150130
Material	Chrome steel
Weight(kg)	1.600
Brand	MIRU / JIB
Packing	Plastic bag+single box+outer carton+wooden pallet
Service	OEM&Customized
Lead time	3-20 days according to the quantity
Payment terms	T/T, L/C, Western Union, Paypal
Gurantee	2 years

Bearing Unit No.	Shaft Dia	Dimensions(mm)	Weight (kg)
d
mm	h	a	e	b	S1	S2	g	w	n	Bi
UCPH202	15	70	127	95	40	13	19	15	101	11.5	27.4	0.92
UCPH203	17	70	127	95	40	13	19	15	101	11.5	27.4	0.91
UCPH204	20	70	127	95	40	13	19	15	101	12.3	31.0	0.96
UCPH205	25	80	140	105	50	13	19	16	114	14.3	34.1	1.20
UCPH206	30	90	165	121	50	17	21	18	130	15.9	38.1	1.60
UCPH207	35	95	167	127	60	17	21	19	140	17.5
