Double Layer Metal Roof Roll Forming Machine Making Two Different Roof Sheets
- T/T L/C D/P D/A
- 7 days
You May Like
-
Color Steel Standing Seam Roof Panel Roll Forming Machine for Roof Sheet
-
PPGI Double Layer Metal Roof Panel Roll Forming Machine 76 mm Shaft Diameter
-
Zinc Corrugated Sheet / IBR Roof Panel Roll Forming Machine with Chain Transmission
-
G550 MPA Zinc Metal Wall Cladding Roll Forming Machine for Wall Profile Panel
-
Imperial Rib Corrugated Roof Sheet Roll Forming Machine Hydraulic Post Cutting
-
Adjustable Hidden Wall PU Sandwich Panel Production Line with PLC Controller
Product Details
| Brand Name | RISHBIN | Place of Origin | China | |
| Model Number | RH-DL- 17 |
Product Description
Certification:CE
Double Layer Metal Roof Roll Forming Machine Making Two Different Roof Sheets
Main technical specification of?double layer metal roof roll forming machine
| Product Name | Item | Description |
| Double Layer Metal Roof Roll Forming Machine | Forming speed | 10-15 m/min |
| Production Material? | Thickness(0.3mm-0.8mm), yield strength≤G250MPa | |
| Number of stations | Upper layer: 18 stations | |
| Lower layer: 20 stations | ||
| Roller material | GCr15 with heat treatment and hard chrome-plated HRC58-62 | |
| Shaft diameter | 76mm | |
| Shaft material | High-quality steel 45 quenched and tempered after finishing treatment | |
| Main motor power | 7.5 kw | |
| Power of hydraulic station | 3.0 kw | |
| Electronic controlling system | Full-frequency PLC controlling system | |
| Cutting | Cutting after forming with hydraulic driving | |
| Material of cutting blade | Cr12 quenched |
Structure of?double layer metal roof roll forming machine
This roll forming machine consists of 5 tons passive decoiler, forming machine, cutter, computerized control cabinet and stacker.
Working process of?double layer metal roof roll forming machine
Coiler loading → feeding-in with guiding (metal sheet is guided into the first forming station) → rolling & forming → cutting → stacker running out
Production Line Sketch
Sample Drawing
Upper layer
Lower layer
Company Introduction
?
Rishbin?was founded in 1999. With more than ten years\' development, now it becomes a leading professional supplier in the field of?roll forming machinery?industry, and exports its quality production?
line to the markets all over the world.
?
We?can?manufacture?as?per?customer?provided?drawings?with?specification?or?real?objects?of?sectional
materials,?custom?roll?forming?machine?is?welcome.?
Contact us
For more information, please contact us freely.
