0.4 mm Thickness Corner Bead Drywall Channel Roll Forming Machine For Wall Frame
- T/T L/C D/P D/A
- 7 days
You May Like
-
Drywall Main Tee Channel Roll Forming Machine with Post Cutting for Ceiling System
-
G550 MPA Steel IBR Metal Roofing Roll Forming Machine with 45 Steel Shaft
-
Double Layer Metal Roof Roll Forming Machine Making Two Different Roof Sheets
-
Color Steel Standing Seam Roof Panel Roll Forming Machine for Roof Sheet
-
PPGI Double Layer Metal Roof Panel Roll Forming Machine 76 mm Shaft Diameter
-
Zinc Corrugated Sheet / IBR Roof Panel Roll Forming Machine with Chain Transmission
Product Details
| Brand Name | RISHBIN | Place of Origin | China | |
| Model Number | RH-DR-220 |
Product Description
Certification:CE
0.4?mm Thickness Corner Bead Drywall Channel Roll Forming Machine For Wall Frame
Specifications of?corner bead drywall channel roll forming machine
|
Product Name |
Item |
Description |
|
Corner Bead Drywall Channel Roll Forming Machine |
Production Material Thickness |
0.4mm , Aluminum |
|
Number of Stations |
10 stations |
|
|
Forming Speed |
30-50 m/min |
|
|
Holes Punching |
1 roller station making holes punching |
|
|
Roller Material |
High quality 45 forged chrome-plated hardware |
|
|
Shaft Diameter |
60mm |
|
|
Shaft Material |
High-quality steel 45 quenched and tempered after finishing treatment |
|
|
Power of Main Motor |
5.5 KW |
|
|
Power of Cutting Motor |
3.0 KW |
|
|
Transmission Type |
Driven by chain |
|
|
Cutting |
Cutting after formed, both hydraulic cutting and flying cut off saw are available |
|
|
Electronic Controlling System |
Full-frequency PLC controlling system |
Structure of?corner bead drywall channel roll forming machine
This roll forming machine consists of 3 tons automatic decoiler, ?feeding, straightener, chain driven transmission,?punching rollers, forming rollers, cutting or shearing device, electric controller and stacker.
Main Components
|
Decoiler / Uncoiler |
1 Unit ? ? ?? |
|
Feeding Guide |
1 Unit |
|
Main Roll Forming Machine |
1 Unit |
|
Hydraulic Cutting Device |
1 Unit |
|
Hydraulic Station |
1 Unit |
|
PLC Computer Control Board |
1 Unit |
|
Runout Table |
2 Units |
Technological process of?corner bead drywall channel roll forming machine
Coiler loading → feeding-in with guiding (metal sheet is guided into the first forming station) →straighten
→ rolling punching → forming→ cutting or shearing → stacker running out
Sample Drawing?
Warranty
The whole equipment including all the components will be guaranteed within one year except improper use.
