Low internal leakage manual control directional proportional hydraulic valve 200L / min

hydraulic directional valve DCV200

200L/min,315bar
G1\"
Very low internal leakage

hydraulic directional valve DCV200

Code:DCV200/3-E2(210)-3S1C2A1-U1G16

Main technical data for DCV200 series sectional control valve as follows:

1.Nominal.Flow:160L/min(=42.27GPM=42.27U.S.gal)

2.Max.Flow:200L/min(=52.83GPM=52.83U.S.gal)

3.Max.Pressure:315bar(=4567.5psi=31.5Mpa)

4.Thread(standard):G1”(we normally provide with BSPP thread,other special thread on require)

5.Working sections:1 to 12 all be ok

6.Spool stroke:+8~-8mm

7.Tie-rod tightening torque:755N.m

8.Allowance backpressure:30bar

9.Parallel circuit(other circuit,such as tandem circuit on request)

10.Low internal leakages

11.High strength cast iron body

12Nickel plated spools

13.100% tested products before shipment

14.ISO 9001:2008 approved

15.Good quality,timely service

16.Factory directly sales

Application

Our products are used in construction,agriculture and machinery,special vehicle for environment sanitation,oil equipment,spaceflight and military area.

The picture we showed is our sectional control valve of DCV200/3 with manual control,all handles at 180 degree.
