Outdoor P10 Single Color LED Traffic Signals for Railway Station 1R 16080 10000 (dot/m2)

Specifications of UC-O-PH10B single color

Catalog

UC-O-PH10SD

LED encapsulation

φ3/φ5 LED

Pixel pitch(mm)

10mm

Module size(mm)

160×80

Module resolution

16×8

Pixel configuration

1R/2R/1R1G/2R1G

Density of pixel(dot/ m2)

10000

Best viewing angle

H: 70°

V: 40°

Max. power consumption (W/ m2)

≤600

Luminance (CD/ m2)

≥4000

Frame change frequency

≥60Hz/s

Refresh rate

≥40Hz/s

Driving mode

1/8Scan
Constant Voltage

Working voltage

AC 220V/50HZ

Working environment

Temperature: ﹣40℃~ +60℃
Related humidity: 10％～90％

Grey scale / color

4096 grades for R, G and B,
Display ≥16.7M color s(synchronized)

Brightness adjustment

Manual adjustment: 256 levels for R, G, B
Automatic adjustment:? 8 grades for each color

Control system??????????

Main controller + Synchronous / off-line control card + DVI display card + Optical fiber transmission (optional)

MTBF

＞10000 hours

Life-span

＞100000 hours
