15.6" LCD Touch Screen HMI PC 160000 Colors ARM9 400MHz CPU Ethernet Port
- T/T L/C D/P D/A
- 7 days
You May Like
-
18 I/O Integrated HMI PLC Software With Allen-Bradley Programmable Logic Controller
-
Industry Integrated PLC And HMI IP65F Cover Transistor Output Control Motors
-
DC 24V Integrated PLC And HMI 3.7 Inch Touch Screen With Operate Buttons
-
Touch Screen Integrated HMI PLC With Siemens Logo And Frequency Inverter
-
256 Colors Touch Screen PLC With HMI Human Machine Interface Power Supply DC 24V
-
Omron PLC Touch Screen HMI Interface Connect U-disk And Export CSV Data
Product Details
| Brand Name | XINJE | Place of Origin | China | |
| Model Number | TGC65-ET |
Product Description
Certification:CE, ISO9001
15.6\" LCD Touch Screen HMI 160000 Colors ARM9 400MHz CPU Ethernet Port
Quick Detail:
15.6?inch LCD,
power supply DC24V,
TG series touch screen HMI (human machine interface),
160000 colors screen display
can communicate with most brand of PLC models
Ethernet function
Description:
High speed for download, start and run
C programming
BMP, JPG picture displaying
3D gallery can make the screen more vividly
Data display mode: time trend map, XY trend map, history trend map…
Self-defined animation track
Export and import the recipe data, improve the efficiency
ARM9 400MHz CPU, 128MB ROM, 128MB RAM
15.6?inch LCD, 16 million colors TFT LCD, LED backlight, resolution 1366*768
2 COM ports, support RS232/RS485/RS422, 2 ports can communicate independently
Built-in real time clock
2 USB port for data transferring and programming
Ethernet communication (communicate with Modbus-TCP device and Siemens S7-1200)
Specifications:
|
Item |
TGC65-ET |
|
|
Electric |
Input voltage |
DC22-DC26V |
|
Current consumption |
730mA |
|
|
Momentary power off allowance |
Less than 10ms |
|
|
Withstand voltage |
AC1000V-10mA 1 minute (signal and time) |
|
|
Insulated impedance |
DC500V- about 10MΩ (signal and time) |
|
|
Port |
COM1 |
RS232/RS485 |
|
COM2 |
RS232/RS422/RS485 |
|
|
USB1 |
USB-A for data transferring |
|
|
USB2 |
USB-B for download program |
|
|
Ambient |
Operate temperature |
0－50℃ |
|
Storage temperature |
-20-60℃ |
|
|
Humidity |
10-90% (no condensation) |
|
|
Withstand vibration |
10-25HZ (X, Y, Z each direction 30 minutes 2G) |
|
|
Noise immunity |
Voltage noise: 1500Vp-p, pulse 1Ms, 1 minute |
|
|
Surrounding air |
No corrosive gas |
|
|
Protection level |
IP65 |
|
|
Screen |
Type |
16 million colors |
|
Screen size |
15.6?inch |
|
|
Using life |
More than 50000 hours, 24 hours running when surrounding temperature is 25 ℃ |
|
|
Resolution |
1366*768 |
|
|
Contrast |
can adjust |
|
|
Language |
English, Spanish, Arabic and so on |
|
|
Character |
Any size and font |
|
|
Touch panel |
4-wire resistance mode |
|
|
Memory |
Screen |
128MB |
|
Construction |
Cooling method |
Natural air coolin |
