4.6" Monochrome LCD Siemens HMI Touch Panel RS485 Port , 2MB Flash ROM
Negotiable
/ Set
1 Set(Min.Order)
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
True Colors 7\'\' LCD Industrial HMI 4-Wire Resistor Touch Screen 128MB RAM
-
AC VFD Variable Frequency Drives 0.75KW Inverter PI Tuning Pure Sine Wave
-
200 Watt AC Servo Drive 400Hz High Speed Response Built-in Brake Resistor
-
16 I/O Micro PLC Programmable Logic Controller DC 24V Modbus Protocol
-
200KHz Pulse Integrated PLC And HMI With 26 Operate Panel Buttons AB Phase Counter
-
32 Digital I/O Integrated PLC And HMI Touch Screen Monitor With PLC , VFD , Servo
Product Details
| Brand Name | XINJE | Place of Origin | China | |
| Model Number | TP460-L |
Product Description
Certification:CE, ISO9001
4.6\" Monochrome LCD Siemens HMI Touch Panel RS485 Port , 2MB Flash ROM
Quick Detail:
4.6 inch Monochrome LCD,
power supply DC24V,
TP series touch screen HMI (human machine interface)
can communicate with most brand of PLC models.
Description:
1. 4.6 inch Monochrome LCD, 240*128 Pixels
2. 2MB FlashROM, 1KBSRAM
3. With data display, data monitor, alarm, recipe and relevant functions
4.?Can communicate with?various popular PLC,?serial communication ports
5. Touchwin software to programming, supports simulate offline and simulate online
Specifications:
|
Electrical
Features
|
Input Voltage
|
DC22-DC26V
|
|
Current Consumption
|
<200 mA
|
|
|
Allowable Momentary Power-cut
|
Less than 20ms
|
|
|
Voltage Endurance
|
AC1000V-10mA for 1 minute
|
|
|
Insulated Resistance
|
DC500V-about 10MΩ
|
|
|
Interfaces
|
Communication Port
|
RS-232/RS-422/RS-485
|
|
Download Port
|
RS-232
|
|
|
Environment
|
Operation Temperature
|
0－50℃
|
|
Storage Temperature
|
-20-60℃
|
|
|
Ambient Humidity
|
20-85%
|
|
|
Vibration Resistance
|
10-25HZ
|
|
|
Interference Rejection
|
Noise voltage: 1000Vp-p, Pulse cycle:1us, Duration: 1minute
|
|
|
Atmosphere
|
Free of corrosive gas
|
|
|
Protect Configuration
|
IP65
|
|
|
Screen properties
|
Type
|
Monochrome
|
|
Screen Size
|
4.6 inch
|
|
|
Lifetime
|
Above 50000 hours,Environmental temperature 25℃,24 hours operating
|
|
|
Display area
|
240*128
|
|
|
Brightness
|
Adjustable (by regulation resistance)
|
|
|
Languages
|
Chinese, English
|
|
|
Font & Size
|
Optional font, Optional size
|
|
|
Touch Panel
|
Digital matrix
|
|
|
Memory
|
Screen
|
2MB
|
|
Data
|
1KB
|
|
|
Structure
|
Cooling method
|
Natural air cooling
|
|
External Dimensions
|
173.2*121.4*45(mm)
|
|
|
Cutout Dimensions
|
165.2*113.4(mm)
|
Applications:?
TP series HMI can communicate with most brand of PLC, such as Siemens, Mitsubishi, Delta, Omron, AB and so on. It also can communicate with frequency inverter and other devices.
