High Precision Brinell Hardness Testing HBE-3000 50Hz / 60Hz Bench for Steel Ball 8HBS - 450HBS

High Precision Brinell Hardness Testing HBE-3000?50Hz / 60Hz Bench for Steel Ball 8HBS - 450HBS

It is improved on a basis of HBE-3000. It serves to measure the Brinell hardness of ferrous metals,

non-ferrous metals. Clear load weight. It adopts electronic automatic load system. It has ten steps

of test force. Test range is more extensiver. Precision is higher.

Specifications:
Test force: 1837.5N (187.5kgf), 2450N (250kgf), 4900N (500kgf), 7350N (750kgf), 9800N
?????????????? (1000kgf), 29400N (3000kgf)
Hardness measuring area: 8-450HBS(Steel ball), 8-650HBW(Hardmetals steel ball)
Accuracy:
<225 HBS(HBW) max.3.0%????????????? >225HBS(HBW) max.3.0
Repeatability 0.06H???????????????????????????? Repeatability 0.03H
(H=Average Value of 5 points)????????????? (H= Average Value of 5 points)
Magnification of microscope: 20x
Max. height of speciments: 240mm
Max. depth of speciments: 260mm
Dimensions (DxWxH): 240x550x775mm
Power supply: AC 220V 50/60Hz
Operating temperature: Test preferably within 23℃5℃
Net weight: 175kg

Standard package
Steel ball indenter2.5/5.0/10mm?? Steel balls 25.5/5.0/10mm???? Reading microscope 20x
V-anvil?? Power cable?????????????????? Flat anvil large??? Manual??????? Flat anvil small
Certificate Fuse Hardness test blocks?? HBS10/3000/30/2025? HBS10/10/1000/30/10025


Optional accessories :

Hard alloy ball 2.5/5.0/10mm?

NAMAS Brinell test plates
Brinell optical scanning System
