DIN 2391 ST35 ST45 Thick Wall Hydraulic Cylinder Pipe , Precision Honed Tube with ISO
- T/T L/C D/P D/A
- 7 days
You May Like
-
St45 St37 E235 E355 Cold Drawn Steel Tube High Pressure for BMW / Fiat / Honda
-
ASTM B633-07 Annealed Galvanized Steel Tube with Thin Wall , Cold Drawing E355 Steel Pipe
-
Round EN 10305-4 EN 10305-1 Galvanized Steel Tubing for Auto , Cold Drawn Steel Tube
-
Cold Drawing Round Hydraulic Cylinder Pipe / E355 DIN2391 ST52 Precision Seamless Steel Tube
-
St52 E235 E355 Seamless Galvanized Steel Tube EN10305-4 E215 for Railway Industry
-
DIN 2391 Cold Drawing Galvanized Steel Pipe for Military , BK BKS BKW ST44 Steel Tubes
Product Details
| Brand Name | JIANGSU HUACHENG | Place of Origin | China | |
| Model Number | HC |
Product Description
Certification:ISO9001 14001 BV TUV PED DNV etc
DIN 2391 ST35 ST45 Thick Wall Hydraulic Cylinder Pipe , Precision Honed Tube with ISO
Quick Detail:
Standards: DIN2391 ST35 ST45
Material Grade: 16Mn / 25Mn / 20# / 45# / 27SiMn / ST45 / ST52 / E355 / A519 SAE1518 / A519 SAE1026 /
Size(mm):
ID :45mm – 500mm
WT:3mm – 50mm
Description:
Standards: DIN2391 ST35 ST45
(GB/T8713 GB/T3639 DIN2391 EN10305 ASTM A519)
Grade: ST35 / ST45
Inside Dimensions: 45mm ~ 500mm
Wall Thickness: 3mm ~ 50mm
Length: max 24000mm
Application: Hydraulic Cylinder
Packing:?Beveled/black painting/ plastic caps/ in bundles/ steel strips/ wooden protection
Inspection and Test:?Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength, Yield Strength,Elongation, Flaring, Flattening, Bending, Hardness, Impact Test),Surface and Dimension Test,Nodestructive Test, Hydrostatic Test.
Surface treatment:Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting.
Mark:?As per customers’ requested.
Delivery Condition:Annealed, Normalized, Normalized and Tempered.
Processing Range And Precision:
|
Cold Drawn Tubes: ID:45mm-630mm Length:14,000mm Straightness:0.3-1.0 Precision:H8-H10 Roughness:Ra0.8-Ra1.6 |
Honing Tubes: ID:25mm-500mm Length:10,000mm Straightness:0.3 Precision:H7-H8 Roughness:Ra0.2-Ra0.8 |
ID Tolerance of Precision Honed Tubes:
|
SIZE of I.D |
I.D.Tolerance |
Tolerance of wall thickness |
||
|
H8 |
H9 |
H10 |
||
|
30 |
+0.0330 |
+0.0520 |
+0.0840 |
<120mm(O.D)???????????????? ±5% ≥120mm(D.D) to 210mm? ±7.5% >210mm???????????????????????? ±10% |
|
>30-50 |
+0.0390 |
+0.0620 |
+0.1000 |
|
|
>50-80 |
+0.0460 |
+0.0740 |
+0.1200 |
|
|
>80-120 |
+0.0540 |
+0.0870 |
+0.1400 |
|
|
>120-180 |
+0.0630 |
+0.1000 |
+0.1600 |
|
|
>180-250 |
+0.0720 |
+0.1150 |
+0.185 |
|
|
>250-315 |
+0.0810 |
+0.1300 |
+0.2100 |
|
|
>315-400 |
+0.0890 |
+0.1400 |
+0.2300 |
Chemical composition:
|
Steel grade |
Chemical composition, as a percentage by mass |
|||||
|
Symbol |
Material number |
C |
Si |
Mn |
P |
S |
|
St 30 Si |
1.0211 |
0.10 |
0.30 |
<=0.55 |
0.025 |
0.025 |
