Home > Products > Bearing Steel Tube > JIS G4805 SUJ2 Seamless Bearing Steel Tube With ISO Certificate , Cold Drawing
JIS G4805 SUJ2 Seamless Bearing Steel Tube With ISO Certificate , Cold Drawing
- T/T L/C D/P D/A
- 7 days
You May Like
-
Grade 1 GR2 Titanium Condenser Tube
-
Round ASTM DIN GB Cold Drawn Bearing Steel Tube / Stainless Steel Pipe With ISO Certificate
-
ASTM B861 GR2 Titanium Tube Seamless , Automotive Exhaust Tube
-
Custom GR2 Titanium Tube Corrosion Resistance For Bicycles ASTM B861
-
Grade 1 GR2 Titanium Condenser Tubes Acid Resistance With ASTM B338
-
Cold Rolled Gr.9 Gr.11 Gr2 Titanium Tube For Heat Exchanger
Product Details
| Brand Name | JIANGSU HUACHENG | Place of Origin | China | |
| Model Number | HC |
Product Description
Certification:ISO9001 14001 BV TUV PED DNV etc
JIS G4805 SUJ2 Seamless Bearing Steel Tube with ISO Certificate , Cold Drawing
Quick Detail:
Products: JIS G4805 SUJ2 Stainless Bearing Steel Tube?
Standard: GB / SKF/ ASTM / DIN / JIS / BS?
Size(mm):
OD:8mm ~ 101.6mm
WT:1.0mm ~ 10mm
Length: Fixed(6m,9m,12,24m) or normal length(5-12m)
Description:
1. JIS G4805 SUJ2 main features and application
JIS G4805 SUJ2 is a kind of high-carbon chromium bearing steel. It has good synthesis performance.Quenching and tempering will make SUJ2 steel high and even hardness, and excellent abrasive resistance and fatigue strength. Good hot workability,after spheroidizing annealing, SUJ2 has good machinability, sensitive to white dot.
JIS G4805 SUJ2 is mainly used to manufacture internal-combustion engine,electric locomotive,machine tool,tractor,steel rolling equipment,driller,steel balls,roller,and axle sleeve of rail truck, mining machine spiale.
2. The equal material of ?JIS G4805 SUJ2 in different standard.
|
|
GB/T18254 |
ΓOCT 801 |
ASTM |
ISO683-17 |
DIN 17230 |
NF A35-565 |
|
SUJ2 |
GCr15 |
IIIX15 |
? 52100 |
1 |
?100Cr 6 |
100Cr 6 |
JIS G4805 SUJ2 chemical composition by %:
|
C |
Si |
Mn |
Cr |
Mo |
P |
S |
others |
|
0.95-1.05 |
0.15-0.35 |
0.25-0.45 |
1.4-1.65 |
≤0.1 |
≤0.025 |
≤0.02 |
Ni≤0.30 |
JIS G4805 SUJ2 mechanical property and delivery condition:
|
?Category |
Standard |
Delivery? Condition |
Anneal (soften or spheroidizing ) hardness? HBW |
|
Hot rolled bar |
JIS G4805 |
Hot rolled,hot rolled soften annealing,hot rolled spheroidizing annealing,hot rolled spheroidizing annealing skin,hot rolled soften annealing skin. |
179-207 |
|
Forging bar |
|||
|
Cold drawn bar |
Cold drawn or burnishing |
||
|
Hot rolled tube/pipe |
Hot rolled,hot rolled annealing burnishing |
||
|
Cold drawn tube/pipe |
Cold drawn |
||
|
Steel ?wire rod |
Hot rolled or spheroidizing annealing |
||
|
Wire |
Annealing |
Quenching HRC≥62 |
|
|
Wire |
Annealing |
φ≤10mm |
|
|
Phosphorus cold drawn |
φ≤10mm |
||
|
Cold drawn,burnishing |
-- |
||
|
Hot rolled or Forging bar,cold drawn bar and wire |
Hot rolled,cold drawn,annealing |
HBW 179-207 |
Applications:
1,Mainly?used for manufact
