Product Details

Brand Name	VISION		Place of Origin	China
Model Number	VS-200

Product Description

Delivery Time:7 working days after received your payment
Certification:ROHSSGS
VS-200 New Design Low Cost Desktop CE Listed Dispensing Robot

Specifications:

1. Proper for a variety of common sealants?
2. 99 programs?
3. CE listed

model	VS-200
Working Range X/Y/Z (mm):?	200/200/50
Load Y-AXIS / Z-AXIS:?	5 / 3 kgs
X&Y / Z ( mm/sec ):	0.1-500/250
Resolution:	0.001 mm/Axis
Repetitive Positioning Accuracy:	0.01 mm/ Axis
Program Capacity:?	At least 100 groups, each group 4000 points
Data Storage Type:?	CF Card
Program Display:?	Teach Pendant LCD
Motor System:?	Micro-step precision motor
Control Method:	PTP & CP
Interpolation Function:?	3 axis ( 3D stereo space arbitrary paths can)
Programming Method:?	Teaching box / PC
I/O Signals Port:?	8 / 8 Outputs Inputs
External Control Interface:?	RS232
Power Supply:?	AC110 220V 300W
Working Temperature:?	10 - 40 C
Working Relative Humidity:?	20 - 90% no condensation
Dimensions (WxDxH mm):?	380X370X500
Robot Weight (kg):?	23kgs

Application

Chevrons, fridge magnets, key chains, power supply, cell phone, energy saving light, LED, DVD, DC, Switch, Connector, relay and other industries needing fluid glue solder.

Applicable objects: Mobile phones, computer case, CD-ROM driver, printer, ink folder, PCB board, LCD, LED, DVD, digital camera, switches, connectors, relays, radiators, semiconductors, clocks, toys and medical appparutus.

Glue type

Silica?gel,?EMI?conductive?adhesive,?UV?glue,?AB?glue,?glue,?epoxy?adhesive,?sealant,?hot?glue,?grease,?glue,

?red?glue,?silver?paste,?thermal?paste,?solder?paste,?transparent?paint,??

Feature:

Teach?Pendant?and?(optional)?PC?programming

Dispense points, lines, surface, circles, arc, irregular curves, three axis controllable.

Can set the glue amount, speed and time etc. Stable glue flow and no leaking.

Four barrels work at the same time to improve efficiency.

Equipped with software that has the area display, translation rotating operation functions.??
