Pancake Slip Ring with 110mm Inner Hole,Electrical Rotary Joint
- 500 Piece / Pieces per Month
- Shenzhen,China
- T/T L/C PayPal Other
- 7 days
You May Like
Product Details
| Brand Name | Victory-Way | Place of Origin | China | |
| Model Number | VSR-P110-16 |
Product Description
When you have a height restriction, a "pancake" slip rings - also called a "flat" or "platter" ring - could be the best solution. These slip ring units are based on a disc shaped rotor, which is embedded with concentric grooves to carry the signal and power, with a brush block assembly mounted over the top to act as the stator. We can customize this type of slip ring from 4 to 50 channels,and any center bore size. Contacts use precious metals and operating speed depends on the number of channels and overall size of slip ring.
A.)Features:
● Ultra-thin design,the thickness reaches 15 mm min;
● Center bore size can be customized;
● Multi circuits/channels design can deliver both power & signal data at the same time.
● Without any maintain.
B.)Specification
| Voltage | 240V AC/DC |
| Current Rating | 10A/Ring |
| Insulation Resistance | 1000M?@500VDC |
| Dielectric Strength | AC 600V@60Hz, 60S |
| Electrical Nosie | 70 milliohms MAX @5rpm,50milliamps,6V DC |
| Contact Material | Precious metal |
| Lead Size/Type | 1.0mm2 Teflon wire |
| Operate Temp | -20℃～ +80℃ |
