24 ways Standard Capsule Slip ring
- 10000 Piece / Pieces per Month
- Shenzhen,China
- T/T L/C PayPal Other
- 10 days
You May Like
Product Details
| Brand Name | Victory-Way | Place of Origin | China | |
| Model Number | VSR-SC24 |
Product Description
SC slip ring capsule is a standard,off-the-shelf unit that uses gold contacts at the rotary interface.Color-coded lead wires are used on both the stator and rotor to distinguish, with double contacts & double precision roller bearings, it utilizes 90°V-groove rings to provide smoother running, lower torque and lower electrical noise. Flame-retardant plastic shell,6, 12, and 24 circuit models for Power and /or signal.
A.）Specification:
| Channels | 1~24 Ways |
| Voltage | 240V AC/DC |
| Current Rating | 2A/Ring |
| Speed | 300PRM |
| Insulation Resistance | 1000M?@500VDC |
| Dielectric Strength | AC250V@60Hz, 60S |
| Electrical Nosie | 60 milliohms MAX @ 5~10 rpm,50milliamps,6V DC |
| Lead Size/Type | AWG28 Sliver plated coppe,Type ET Teflon |
| Lead Lengths | 250mm |
| Operate Temp | -20℃～+80℃ |
| Storage Temp | -30℃～+90℃ |
B.）Features:
● Compact miniature design, small size,fit for harsh space;
● Double precision roller bearings for lower torque & long life;
● Signal and power can be combined to deliver in the same slip ring;
● More installation flanges for option.
More product information welcome to visit .
