100 x 120mm Automatic Heavy Duty Gabion Mesh Machine With 3.0mm Wire Diameter

100 x 120mm Automatic Heavy Duty Gabion Mesh Machine With 3.0mm Wire Diameter

Quick Detail:

1.The series gabion mesh machines have been designed to make gabion mesh of various widths and mesh

sizes.

2.The possible coatings are heavily galvanized and zinc.

3.For high corrosion resistance, zinc and PVC coated wire is available

Gabion Application

Gabion?Machine?widely?used?in?oil,?construction,?raising,?chemical?industry?warming?piping?and?etc.?It?is?also?

used?in?fence,?apartment?and?greening.?The?hexagonal?wire?netting?can?be?used?in?protect?sea?wall,?hillside,?

road,?bridge?and?civil?engineering.?It?is?one?of?the?best?against?flooding?material.

Specifications:

1.?Mesh?sizes:?100x120mm

2.?twist:?double?twist

3.?Max.?netting?width:?2300mm

4.?Max.?galvanized?wire?diameter:?1.6-3.2mm

5.?Max?PVC?wire?diameter:?4.2mm

6.?Spindle?Speed:25r/min

7.?Power:?11Kw

8.?Weight:?15MT

9.?Theoretic?output:?225m/hr

10.?Automatic?stop?system?(option):?when?the?coiling?finished?or?wire?broken,?the?machine?will?stop?

automatically

11.?Infrared?ray?safety?protection?system?(option)

12.?Automatic?oil?system

Gabion Machine Working

Gabion Machine Packing

A set of gabion machine will be loaded to one 40\' container, it is nude packing and will use wire to fix the machines in the container, make sure it is safe on passage.

Workers are fixing the machine

Machines?are fixed in the container as below picture

Gabion Machine Was Unloaded in Foreign Country

Competitive Advantage:

1. JINLIDA company invented the first special equipment of double twisted wire netting making machine in

China (patent number: ZL99229381.2 and ZL00267066.5). And until now, we have persevered in this area

of gabion machine making for 15 years.

2. All the parts of gabion machine are processed by our own factory; no parts were send to outside to

process, so the quality can be ensured.

3. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our

technician to help install the machines in your country, and also could supply all the spare parts with cost

price if customer need.
