Home > Products > Welded Pipe Mill > 11Inch Longitudinal Straight Seam Welded Pipe Mill Line with Water Cooling System from 0.3 to 12mm
11Inch Longitudinal Straight Seam Welded Pipe Mill Line with Water Cooling System from 0.3 to 12mm
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
15KW Door Frame Roll Forming Machine, Hydraulic Automatic Cutting
-
C / Z / U Section Roll Forming Machine for Purlin Profiles
-
Longitudinal Straight Seam Welded Pipe Mill Line with 0.3-1.0mm Thickness for Custom Steel Pipes
-
0.5 - 1.5mm Material Thickness Stud & Track Roll Forming Machine
-
HS41-210-420 Concealed Roof Panel Rool Forming Machine
-
Straight Seam Welded Pipe Mill , ZG45 Tube Mill Line for Round / Square Pipes and Rectangle Pipes
Product Details
| Brand Name | HS | Place of Origin | China | |
| Model Number | custom made |
Product Description
Certification:ISO9001, CE
11Inch Longitudinal Straight Seam Welded Pipe Mill Line with Water Cooling System from 0.3 to 12mm
Precision high frequency Longitudinal welded pipe mill line
Tube Mill, Steel Pipe Production Line, Pipe Mill
1. To make steel pipe O.D. from 0.3 to 11inch(8mm to 273mm)
2. Wall thickness from 0.3 to 12mm.
The complete line include the following device:
1. Double side Uncoiler
2. Hoop cage or Horizontal Accumulator
3. Main Machine:
3.1. Forming Machine
3.2. Roller System of Forming
3.3. Seam Guide
3.4. High Frequency Induction Welding Machine
3.5. Roller System for Moving
3.6. Burr Removing Frame (Inside and outside Burr )
3.7. Water Cooling System
3.8. Sizing Machine
3.9. Roller System of Leveling
3.10. Speed Testing Wheel
3.11. Turkish Frame
4. Auto Flying Saw Controlled by Computer
5. Run out table
6. Electric Control Equipment
7. High Frequency Welding Machine
The technical parameters of Precision High Frequency Longitudinal Welded Pipe Mill line:
|
Equipment Type |
Outside Diameter(mm) |
Thickness (mm) |
Production Rate (m/min) |
|
ZY16 |
7.6-16 |
0.3-1.0 |
0-100 |
|
ZY20 |
10-25 |
0.3-1.5 |
0-100 |
|
ZY32 |
13-38 |
0.6-1.8 |
0-100 |
|
ZY45 |
16-50 |
0.7-2.0 |
0-90 |
|
ZY50 |
20-63.5 |
0.8-3.0 |
0-80 |
|
ZY60 |
25-76 |
1.0-3.2 |
0-80 |
|
ZY76 |
32-89 |
1.2-3.75 |
0-80 |
|
ZY89 |
35-100 |
1.2-4.5 |
0-70 |
|
ZY125 |
50-130 |
2.0-5.0 |
0-60 |
|
ZY165 |
76-165 |
2.0-6.0 |
0-50 |
|
ZY219 |
89-219 |
3.0-8.0 |
0-50 |
|
ZY273 |
100-273 |
4.0-12.0 |
0-45 |
|
ZY325 |
89-325 |
3.0-12.7 |
0-40 |
|
ZY406 |
114-406 |
4.0-16.0 |
0-40 |
|
ZY508 |
219-508 |
4.0-19.1 |
0-40 |
|
ZY610 |
219-610 |
4.0-19.1 |
0-40 |
|
ZY660 |
219-660 |
4.0-22.0 |
0-40 |
