R8M 2 Strands , Continuous Casting Machine Rigid Dummy Bar

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 0 Set / Sets per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HAIJUN		Place of Origin	China
Model Number	R8M 2 strands

Product Description

Delivery Time:2 months

R8M 2 Strands , Continuous Casting Machine Rigid Dummy Bar

ntinuous casting machine (CCM) / continuous steel casting
2,kinds of arc radius?
3,kinds of billet type?
4,kinds of strand?
5,More options

We can produce high quality continuous casting machines from 1 to 8 strands with the lowest equipment manufacturing cost.We can design, manufacture the up-to-date billet continuous casting machine in accordance with the user\'s steelmaking capacity, billet size, steel grades and the user\'s field conditions.

1. Basic standby technical parameters:

Steel billet casting machine radius	8m
Strand quantity	2 strands
Ladle support type	Ladle turret or Ladle car
Tundish carriage	Semi-portal, cross sliding function
Casting method	Metering nozzle, open casting
Secondary cooling	Gas and water cooling , 2 adjusting circuit
Withdrawal straightening machine	Totally 5 roller, progressive straightening
Roll table	Chain group centralized drive
Dummy bar	Rigid, with self-adapting dummy bar head
Billet cutting	Hydraulic or flame cutting machine
Billet conveying	Group centralized live roller table
Cooling bank type	Simple cooling bed

2. Technical process description and capacity of steel billet CCM

Induction furnace:

Nominal capacity	30T
Tap-to-tap cycle?	60min
Furnace quantity?	3sets

Production capacity?

Working days	330 days/year
Average number of daily furnace	24/day
Production capacity	300,000t/year

3. ?Casting speed, productivity and strand quantity

R8m radius casting machine can cast steel groups of different specifications, the maximum casting speed is as follows:

Casting sectional area(mm)	?180x180	200×200	220×220
Casting speed(m/min)	1.6	1.8	2.0

NO.	Billet size	Casting speed	hourly output (tons)	Daily output 20hour (tons)???	Annual output(300days) (tons)
1	180×180	1.6m/min	21.98	439	131,700
2	200×200	1.8m/min	27.13	543	162,900
3	220×220	2.0m/min	36.47	729	218,700

The calculation results is the ideal state of the production, please according to own actual situation of adjustment.

Steel grade	Casting grade(m/min)	Effective deformation rate(ε)	Allowable deformation rate(εmax)
Straight carbon steel	1.8～2.5
