4kw Vector Control AC Frequency Drives / Motor Drive 220v ,380v ,460v

Brand Name	POWTECH		Place of Origin	China
Model Number	PT200 004G-1B

Delivery Time:3-7days
Certification:CE,ROSH,FCC
4kw Vector Control AC Frequency Drives / Motor Drive 220v ,380v ,460v Quick Detail: Power range:0.75kw - 630kw , Voltage range:220v,380v,460v,±15% , Input phase:single phase input,?3-phase input , Size:189.5/167/120mm, 1650/480/830mm, Weight:2-500kg Product Features:

High-Performance Vector Frequency Inverter

LED/OLED Multi-function control keyboard One?key shuttle encoder Motor parameter self learning DSP high speed chip control unit Description:

Powtech PT200 Series High-performance Vector Control?AC Motor Drive?Range:

Model	Phase Input	Power(kw)	Voltage(Vac)
PT200 G1	1 Phase	0.4kw -7.5kw	220v±15%
PT200 G2	3 Phase	0.4kw-220kw	220v±15%
PT200 G3	3 Phase	0.4kw-630kw	380v±15%
PT200 G4	3 Phase	0.4kw-630kw	460v±15%
PT200 G6	3 Phase	30kw-780kw	575v±15%

Performance Introduction:

PT200 Series Range

AC frequency vector inverters type	Input voltage	output?? rating (kW)	Rated input current(A)	Rated output current(A)	Adaptive motor

PT200-0R4G-1B

Single phase 220V

±15%

0.4

5.4

2.3

0.4

PT200-0R7G-1B

0.75

8.2

4.5

0.75

PT200-1R5G-1B

1.5

14.2

7.0

1.5

PT200-2R2G-1B

2.2

23.0

10

2.2

PT200-0R7G-2B

Three phase 220V

±15%

0.75

5.0

4.5

0.75

PT200-1R5G-2B

1.5

7.7

7

1.5

PT200-2R2G-2B

2.2

11.0

10

2.2

PT200-004G-2B

3.7

17.0

16

3.7

PT200-5R5G-2B

5.5

21.0

20

5.5

PT200-7R5G-2B

7.5-

31.0

30

7.5

PT200-011G-2B

11.0

43.0

42

11.0

PT200-015G-2B

15.0
