Eight working station coil winding machine
Negotiable
/ Kilogram
1 Kilogram(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Automobile Alternator Stator Wave Winding Machine
-
Automatic Coil Winding Machine / Wire Winding Equipment High Performance
-
Small Alternator Armature Coil Winding Machine
-
Automatic Ceiling Fan Coil Winding Machine
-
high speed wide flexo printing machine for paper , polyethylene Flexographic Printing Machine
-
Multi Color digital printing machine for Roll Paper / Plastic Film / Non Woven / Fabric
Product Details
| Brand Name | Nide | Place of Origin | China | |
| Model Number | RXL3-100 |
Product Description
Certification:None
Eight working station coil winding machine
Quick Detail:
1.?Model No.:?RXL3-100
2. this machine has 8 work stations.?
3. This machine has a variety of application.
4.?wire tension is stable and adjustable.
Description:
This machine?has four winding heads and eight operation stations. High efficiency is its feature. The machine automatically put the coil into transfer former orderly, especially suitable for high production capacity requirement, high slot filling rate, small slot opening stator coil winding. Winding mode, such as auto skip, auto cutting and auto indexing could be completed at a time successively, parameter could be set in human-machine interface. Continuous/discontinues winding way and meets the 2 poles. 4 poles, 6 poles coils winding.
Technical Parameter:
Wire diameter: 0.19~1.2mm Swing diameter: 220mm Operation station: 8 Winding head: 4 Max stack height: 100mm Max stator OD: 120mm Max RPM: 2500RPM Air source: ≥0.5MPa Power supply: 380V 50/60HZ 15KW Weight: about 5000KG Dimension:(L)2100*(W)1350*(H)2200mmCompetitive advantages:
It is an eight-station?coil winding machine suitable for all kinds of frame winding, electronic winding and combined motor winding.
