aluminum magnet wire colored aluminum wire

FOB Price

USD $2.5 - $4.75 / Kilogram

200 Kilograms(Min.Order)

Supply Ability 40 Ton / Tons per Month
Port Qingdao or Shanghai
Payment TermsT/T D/P D/A

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Henan, China	Brand Name	Amity or OEM
Model Number	enameled aluminum wire	Type	Insulated
Application	Other, motors,transformers&generators	Conductor Material	Other, Aluminum,Copper,CCA
Conductor Type	Solid	Insulation Material	Enameled

Product Description

Specifications

1.class120,130,155,180,200,240 colored aluminum wire
2.Dia.(mm):flat :a:0.8-5.6,b:2.0-16;round:0.13-6.0
3.ISO,UL,Rohs approve

colored aluminum wire

We are the 120,130, 155,180,200,240 degree colored aluminum wire manufacturers with required standard

and competitive price.

1.Round colored aluminum wire

Series	Standard	Size available	Properties	Applications
Polyester aluminum magnet wire (130°C&155°C)	IEC60317-0-3:2008	0.13-3.0mm	Good mechanic and chemical properties	general motors of Class B&F motors and coils of electrical instruments
Polyesterimide round aluminum magnet wire (180°C)	IEC60317-15:2010 IEC60317-0-3:2008	0.13-6.0mm	excellent propertities in heat shock and cut-through testing	motors,generators and dry-type transformers working at 180°C
polyesterimide overcoated polyamideimide round aluminum magnet wire (200°C)	IEC60317-52:2010 IEC60317-0-3:2008	0.13-6.0mm	1. excellent propertities in heat shock and cut-through testing 2.able to bear corona performance,solvents,refrigerant	Especially suitable for frequency conversion and control of motor winding in: a) Frequency conversion refrigerators b) Frequency conversion air conditioner compressor c) Electromechanical winding d) Other electrical machineries with the same demands

2.rectangular colored aluminum wire

Rectangular flat colored aluminum wire is a kind of winding wire,first the ectrical round aluminum rod is extruded

or drawed into high quality aluminium conductor,then it is insulated by the varnish.They are mainly used in motors, transformers, generators and other electrical equipments.

Parameter	SMCB-120	SMB-130	SMGB-155	SMYB-180	SMYB-200	SMCYB-240
Standars	MW 18 IEC60317-18 GB/T7095.2	IEC60317-16 GB/T7095.7	IEC60317-16 GB/T7095.3	IEC60317-28 GB/T7095.4	MW 36 IEC60317-29 BS6811 GB/T7095.6	MW 20 IEC60317-47 GB/T7095.5
Thermal Class	120°C	130°C	155°C	180°C	200°C	240°C
Enamel Base Coat	Polyester-formal	Polyester	Modified Polyester	Polyester-Imide	Polyester-Imide	Polyimide
Enamel Top Coat					Polyester-Imide
Range of insulation thickness	IEC60317-0-2 G1,0.06-0.11mm G2/0.12-0.17mm
Heat shock	155°C	155°C	175°C	200°C	220°C	300°C
Performance	1.Excellent bending property 2.High flexibility of the enamel 3.Good resistance to abrasion 4.High mechanical property	1.Excellent bending property 2.High flexibility of the enamel 3.Good resistance to abrasion 4.High mechanical property	1.Excellent bending property 2.High flexibility of the enamel 3.Good resistance to abrasion 4.High mechanical property 5.Higher thermal property	1.High thermal resistance 2.Suitable for windings that are subjected to constantly high temperature and mechanical stress 3.Good chemical resistance	1.Excellent thermal resistance 2.Suitable for windings that are subjected to constantly high temperature and mechanical stress 3.Good chemical resistance 4.Good resistance to refrigerant and freon	1.Excellent thermal resistance suitable for any electric equipments that are constantly exposed to high working temperature 2.Outstanding mechanical and chemical property 3.Good performance against radiation
Application	1.Dry and oil-immersed transformer 2.Electrical equipment	1.Dry and oil-immersed transformer 2.Electrical equipment	1.Dry and oil-immersed transformer 2.Electrical equipment	1.Windings of high and low voltage DC/AC motor 2.Magnet coil 3.Dry and oil-immersed transformer	1.Windings of high and low voltage DC/AC motor 2.Magnet coil 3.Dry and oil-immersed transformer 4.Automobile coil 5.Train coil	1.Windings with service temperature up to 220°C 2.Motor and generator for aviation and marine application 3.Nuclear industry 4.Windings requiring high reliability
