PVC / PE Plastic HDPE Pipe Extrusion Production Line Equipment 110mm ~ 250mm with Single Screw Extru

Brand Name	POLYTECH		Place of Origin	China

Delivery Time:30 days after perpayment
Certification:ISO9001-2000；CE

PVC / PE Plastic HDPE Pipe Extrusion Production Line Equipment 110mm ~ 250mm with Single Screw Extruder?
?

Quick Detail:

The HDPE pipe extrusion line is mechanotronics, with the advantages of:
1) highly automated;
2) easy to operate;
3) continuous production with stability and reliability
?
?
Description:

The HDPE pipe extrusion line mainly consists of control system,extruder,die,calibration system,haul-off unit,planet cutting device and stacking device. Each line has two extruders, the main one adopts strong convey bush and high-efficient screw, the smaller one is mainly used for extrude marking line.
?
?
?

Specifications:

Model	SJGZ-63	SJGZ-160	SJGZ-250	SJGZ-450	SJGZ-630
Pipe diameter	Φ20~Φ63	Φ50~Φ160	Φ110~Φ250	Φ160~Φ450	Φ315~Φ630
Extruder	SJ65/33 SJ25/25	SJ75/33 SJ25/25	SJ90/33 SJ30/25	SJ120/33 SJ30/25	SJ30/25 SJ120/33
output	100-120	150-250	280-300	350-700	350-800
Main dirve motor	55	55	130	180	180

?
?
Competitive Advantage:

The HDPE water supply pipe extrusion machine has unique structure, it is highly automated, easy to operate,continuous production with stability and reliability.
?
?
Applications:
?

The pipe product of HDPE water supply and gas supply pipe extrusion machine has proper rigidity,intensity,and good flexibility,good creep-resistance,environmental stress crack resistance and good melt ability, already been the best choice of ?the gas and water supply pipe in the city.
?
?
Advantage of the HDPE water supply and gas supply pipes:

Non-toxic: no heavy metal additives ,would not be covered with dirt or contaminated by bacterium Corrosion Resistant: resist chemical matters and electron chemical corrosion Low Flow Resistance: smooth interior walls and low friction Easy installation: light weight and handed friendly Longevity: more than 50 years under proper use Various Joint Availability: socket fusion joint, butt fusion joint, electro fusion joint and transition joint Recycled and Environment-friendly

?

?


HDPE pipe extrusion line, pipe extrusion machine, single screw extruder
