Home > Products > Maglev Wind Power Generator > High Efficiency Maglev Wind Power Generator 3KW Wind Turbine Maglev
High Efficiency Maglev Wind Power Generator 3KW Wind Turbine Maglev
Negotiable
/ Piece
1 Piece(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Magnetic Wind Turbine Solar And Wind Powered Street Lights Customized
-
Roof Mounted VAWT Maglev Vertical Axis Wind Turbines For The Home
-
Monitoring System Power Supply Solar And Wind Powered Street Lights
-
Commercial Magnetic Levitation Vertical Axis Wind Turbine 200w 300W
-
300W VAWT Maglev Wind Solar Hybrid Street Light System With Doulbe LED Lamps
-
Aluminum alloy 400W Maglev Wind Generator Domestic Hybrid PV System
Product Details
| Brand Name | TYPMAR | Place of Origin | China | |
| Model Number | CXF-3000 |
Product Description
Certification:CE ISO9001 IEC
High Efficiency Maglev Wind Power Generator 3KW Wind Turbine Maglev
1. Brief to 3kw wind turbine
CXF-3000 Vertical Axis Maglev Wind Turbine is a breakthrough in wind power technology. It’s Typmar who made magnetic levitation technology used in wind turbine for the first time. This creates a milestone and fulfills important breakthrough in the history of small and medium wind turbine development. The maglev technology improves the efficiency of wind power 35% compared to traditional horizontal axis wind turbine. The innovative wind generators have been widely used for Telecoms Base Receiver Station (BTS) as well as residential and commercial applications.
2. Feature:
Magnetic levitation technology Independent of the direction of the wind Startup at low wind speed of 1m/s Higher efficiency compared to traditional HAWT Works even in turbulence Visually pleasing appearance Turbine construction is resistant to gale 60m/s (132MPH) Robustness and adaptation to all possible environmental conditions thanks to material of aluminum alloy or stainless steel Design life: at least 20 years Noise: Tested by China National Machinery Quality Inspection Centre at 12m/s: <40db3. Specifications
| Items | CXF3000-Ⅰ | CXF3000-Ⅱ |
| Rated power | 3000W | 3000W |
|
Dimension (Height/Diameter) |
3530/?3600 | ?4160/4570 |
| Weight | 415KG | 680 kg |
| Blade material | Aluminum Alloy | Aluminum Alloy |
| Blade quantity | 3 | 3 |
| Swept area ㎡ | 7.02 | 7.72 |
| Min starting wind speed | 1.5m/s | 1.5m/s |
| Cut-in wind speed | 3.5m/s | 3.5m/s |
| Rated wind speed | 13m/s | 13m/s |
| Cut-off wind speed | 15m/s | 15m/s |
| Survival wind speed | 60m/s | 60m/s |
| Generator type | AC,3Phases | AC,3Phases |
| Controller Output Voltage | 48V | 96V |
| Controller Braking System | 3-phase short circuit by NFB brake | 3-phase short circuit by NFB brake |
| Ambient Temperature | -40～50 ℃ | -40～50 ℃ |
| Noise | Tested by China National Machinery Quality Inspection Centre at 12m/s: <40db |
4. Application :
Off-grid and grid-tie power systems for residential and commercial application as well as Telecoms (BTS)
