A Starjet 7701 Epson Eco Solvent Printer 1440 DPI With CMYK Color

Type: inkjet printer

Brand Name: A-Starjet

Place of Origin: Changzhou

Automatic Grade: Automatic

Usage: digital vinyl printer

Certification: CE

Voltage: AC 100-220V

Model: 7701

Weight: 360 kgs

Color: CMY / CMYK

Keyword: eco-solvent printer

After-sales Service: Yes

Item

A- Starjet 7701

Print head

one DX7 print head

Number of nozzles

1440 nozzles per head

Color

4 Colors:Cyan,Magenta,Yellow,Black

Resolution

1440dpi(max)

Height of print head

2～5mm

Size of ink droplet

1.5～21pl

Printing width

1800mm

Speed

3pass? 17.0sq.m per hour

4pass? ?13.0sq.m per hour

6pass ??8.5sq.m per hour

8pass? ?6.5sq.m per hour

Media width

1900mm

Media take up

Yes

Media feeder

Option

Media payload

70kgs

Heating system

Print heater and Post heater with PID temperature control temperature range:room temperature to 80℃

Ink

T5.5 eco-solvent ink

ST5.5 water-based dye ink

T7 reactive printing ink

Ink cartridge

8×350ML continuous ink supply, Optional bulk system

Rip software

iPrint3.0? 16bit

Control software

Print console

Operation system

MS Windows XP ﹠ Windows 7

Interface

USB2.0

Power voltage

AC 220～240V 50～60Hz or AC 110～120V 50～60Hz

Printing environment

Temperature:20～25℃,humidity:40-60%

Printer dimension

W2840×D900×H1250mm

Packing dimension

W2920×D980×H700mm

Net weight

220kgs

Gross weight

360kgs
