Multi Core 1.8 / 3KV Low Votage PVC Insulated Cable / Armoured Cabling
- T/T L/C D/P D/A
- 7 days
You May Like
-
1kv Fire-resistant PVC Insulated Cable / Steel Wire Armoured Cable
-
3 Core PVC Insulated Electrical Armoured Cable And Wires Copper Conductor
-
Low Voltage PVC Insulated Cable Low Smoke Zero Halogen Power Cable
-
Low Voltage PVC / XLPE Insulated Aluminum / Copper Conducor 4 * 240mm2 ABC Cable
-
Multicore 0.6 / 1kv PVC Insulated Copper Cable Wire , 3 Core Electrical Cable
-
XLPE Insulated Thin Steel Wire Armored PVC / PE Sheathed Electrical Cable And Wire
Product Details
| Brand Name | Sunlight | Place of Origin | China | |
| Model Number | VV |
Product Description
PVC-Insulated Cables
1.High Degree Copper Conductor
2.Durable outer Sheath
3.Quick Delivery & Reliable Quality
4.CCC Honor
?
PVC-Insulated Cables
Model No : W22.5*16 Low Votage VV
1. The cable?was suitable for?AC rated voltage not exceeding 3.6/6KV.
2. All the characteristics & Technology?are?referenced by?
??? A:?National?Standard?GB/T12706-2008
????B: International Standard ?IEC60502-1:2004,60502-2:2005
3.The Sheathing Insulated Power Cables with the Rated Voltage 1kv to 35kv and Its Attachment
The sue characteristic? &?index of electrical characteristics:
A.Suitable installation temperature:≥0°C B.Regular working ?temperature of conductor:≤70°C C.Under the condition of short circuit(the max. ?? continuing time should not exceeding 5 seconds) the max. ?? operation temperature:160°C D.the permissible minimum bending radius: ?? ?single core:20D?????? multicore: 20DE:??The Following Tested cables of the Ac Votage
|
KV Rated voltage |
0.6/1 | 1.8/3 | 3.6/6 |
|
KV Test voltage |
3.5 | 6.5 | 12.5 |
|
min Continuing time(min.) |
5 | 5 | 5 |
F: The DCR of conductor comply with the rules of GB/T3956-2008 The Conductor of Cables
|
Type |
? | Name | Suitable? Range |
|
Copper-Conductor |
Aluminum-Conductor |
? | |
|
?VV |
?VLV |
PVC insulated and sheathed power cable |
? Installation in such place as indoor, ? tunnel, pipeline, cable channel, and flammable and deep-corrosion areas; the mechanical ? force is unavailable |
| ?VY | VLY? |
?
PVC insulated and sheathed power cable |
? Installation in such place as indoor, ? tunnel, pipeline, cable channel, and flammable and deep-corrosion areas; the mechanical ? force is unavailable |
| ?VV22 | ?VLV22 |
?
insulated and sheathed ? cable with copper tape |
?
Installation in such place as indoor, cable channel, underground and deep-corrosion areas; the lager tension is ? unavailable. |
| ?VV23 | VLV23? |
?
PVC insulated and sheathed cable with steel tape |
?
Installation in such place as indoor, ? cable channel, underground and deep-corrosion areas; the lager tension is ? unavailable. |
| ?VV32 | VLV32 |
?
PVC insulated and sheathed cable armored with thin steel wire |
?
Installation in such place as underground, ? vertical shaft, water and deep-corrosion areas; the lager tension is ? unavailable. |
| ?VV33 | VLV33? |
?
PVC--insulted and polythene—sheathed ? cables armored with thin steel wire |
? Installation in such place as underground, ? vertical shaft, water and deep-corrosion areas; the lager tension is?unavailable |
| ?VV42 | VLV42? |
?
PVC insulated and sheathed cable armored with thick steel ? wire |
?
Installation in such place as underground,vertical shaft, water and deep-corrosion areas; the lager tension is?unavailable. |
