Cold Drawn Seamless Hydraulic Tubing For Oil Delivery Pipe , DIN2391/C / EN10305-4

Cold Drawn Seamless Hydraulic Tubing For Oil Delivery Pipe , DIN2391/C / EN10305-4

Specifications:

·Standard:ISO8535-1/DIN2391/C/EN10305-4?/SAEJ524

·Material:ST35,ST37.4,ST37,ST45,ST52,ST52.4,E235,E255,E355,SAE1010,SAE1020

·OD:6MM-16MM,ID:1MM-6MM

·Delivery?State:NBK/GBK.

·Raw?material:Bao?Steel,Huai?Steel,XingCheng?Steel?with?good?quality.

·Length:5.8m,6m.

·Package:Bundles?or?wooden?cases.

·Surface?Anti-rust:Both?outside?and?internal?tube?surface?flushing?with?anti-rust?oil.

·Surface?quality:very?smooth?and?bright?without?oxide?scale,pock,strach,crack?and?other?defects..

·Surface?Cleaness:clean?without?iron?scrap,dust,better?for?hydraulic?system?life.

·High?working?pressure,better?extending?rate?and?strength?property,after?bending?with?no?deformation,a ? fter?flattening?and?flaring?process?with?no?crack.

·Raw?material:Bao?Steel,Huai?Steel,XingCheng?Steel?with?good?quality.

·Test:Tensile?Strength?Test,Flaring?and?flattening?test,Water?Pressure?Test,Hardness?Test,Chemical?C ? ompositon?Test?

Description:

Synopsis of Process Flow: using high quality BaoSteel: ST35, ST37, ST37.4, ST52.4, cold drawn, none oxidization heat treatment(NBK), none destructive inspection.

Applicable Standard: ISO8535-1 (steel tubes for high pressure fuel pipe in compression ignition engine), ISO0404-1992(technical requirements for steel and steel product) ISO6892-1984 (tensile testing for metal )

Main Features: High precision,excellent brightness,no oxidization scale, high cleanness inner surface, flushing the inner diameter, antirust oil painted. total impurity<1.5mg/m, maximun granule 8 degree(≤0.2mm), withstand high pressure, no deformation after cold bending, the complicated geometrical forming and machining can be realized.

color of the tube: gray with white. the tolerance for OD and ID: ±0.05, quality inner surface: Grade Q,work pressure2000 kilos, max testing pressure: 6000 kilos without deformation, 180 bending degrees without cracks.

Applications:

For high pressure fuel pipe in compression ignition engine, all technical requirements call reach the level of top international brand, be able to replace the imported tubes and reduce the cost for our customers.

Specifications:?

Standard:ISO8535-1/DIN2391/C/EN10305-4

Competitive Advantage:

Mechanical property test,hardness test,water pressure test,roughness test.All above test can be achieved by us.

Certificate awarded:TS16949.

Main Customer:Contitech,Benteler.

We have cooperated with Volkswagen.

We also have been reviewed by BMW.

Production Line:

Production Equipment:

?Packing and loading:

?Laboratory Testing:

Our Customer:

Certificate Approved:
