Electronic Rotary Tablet Press Camphor Tablet Making Machine 380V With 19sets

Brand Name	wangqun		Place of Origin	China
Model Number	ZP19D

Delivery Time:7-10 days
Certification:ISO 9001:2000，CE

Electronic Rotary Tablet Press Camphor Tablet Making Machine 380V With 19sets

Quick Detail:

rotary tablet press,tablet press machine automatically continuous rotary tablet press Number of Dies:19sets Max. Pressure:60kn Max Production Capacity:29000pc/h Warranty:1 year

Description:

The machine is an automatically continuous rotary tablet press that are widely used in pharmaceutical, chemical, ceramics, foodstuff , electronics, plastics and powder metallurgy industries, etc. The machine is applicable to the pressing of? a variety of granular materials into tablets, but not applicable to the pressing of semi-solid, wet and ultra-fine powder particles .

1. Machine drive: motors (stepless speed regulation is controlled by inverters) → pulley driven→ worm driven→ turntable driven by the spindle for rotating clockwise.

2. The technological process for tablet pressing of this machine is material feeding, filling, tablet pressing and tablet out continuously.

3. When working, turntable with 19 sets of dies drives for rotating clockwise. Dies move up and down along track curve, and complete pressing movement through the pressure roller .

4. Rolling friction installations of up and down rollers will help reduce resistance and lower power consumption.

5. The safety roller unloading device on the below axle pressed by a spring balance, with their working pressure adjustable by the spring. When over-pressure occurs , the spring housing automatically unload, acting as a protection punch.

6. Filling, film thickness, rotation speed and other parts are regulated by centralized control unit for easy operation .

7. Submerged lubrication are used for the worm and worm gear units to reduce the power loss and extended service life.

8. The external part of the machine is fully-enclosed, so that sealed pressing rooms and drive mechanism can be totally separated from each other to prevent dust and avoid cross-contamination .

9. Dust collector are installed to remove dust automatically .

Applications:

widely used in pharmaceutical, chemical, ceramics, foodstuff , electronics, plastics and powder metallurgy industries , etc. This machine is suitable for pressing round tablets form various kinds of granular materials, and can be also used to press irregular tablets of different geometrical shapes

Specifications:

Number of Dies	19 sets
Max. Pressure	60 KN
Max? Dia. of Tablet	20 mm
Max Depth of Tablet	12 mm
Max Thickness of Tablet	6 mm
Diameter of up and down punch pole	22mm
Length of up and down punch pole	115 mm
Thickness of medium mould	22mm
Dia. of medium mould	26 mm
Max Production Capacity	34000 pc/h
Overall Size(L*W*H)	820*610*1680 mm
Net? Weight	860 kg
Motor Power	3 kw
Motor Speed	1440 r/min
Voltage	380 V

Competitive Advantage:

an automatically continuous rotary tablet press suitable for production of small scale Overload protection unit is included in the system pressing round tablets form various kinds of granular materials meet the GMP requirement used in pharmaceutical, chemical, ceramics, foodstuff , electronics, plastics and powder metallurgy industries
