Home > Products > Chimei LCD Panel > 12.1" LVDS CMI Innolux TFT LCD panel G121X1-L03 Industrial Grade for Laptop,Notebook
12.1" LVDS CMI Innolux TFT LCD panel G121X1-L03 Industrial Grade for Laptop,Notebook
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
TM043NDH02 4.3 inch Tianma TFT LCD Display Module WLED Backlight
-
Mini TV / GPS Tianma 4.3 Inch TFT LCD Touch Screen Monitor TM043NDH02
-
12.1\" AUO LCD Panel G121XN01 V0 for Medical Equipment , ATM , POS
-
AUO 12.1\" TFT LCD Panel G121XTN01.0 for Industrial Laptop Screen
-
122*32A COB Graphic Monochrome LCD Module for Security system
-
Mini WLED Backlight Monochrome LCD Module Transflective 8 Bit Parallel Mode
Product Details
Brand Name | CMI | Place of Origin | China | |
Model Number | G121X1-L03 |
Product Description
Certification:CE,ROHS, FCC
12.1\"?LVDS?CMI Innolux TFT LCD panel?G121X1-L03?Industrial Grade for Laptop,Notebook
Quick Detail
1. Part No:G121X1-L03
2. Size:12.1nch
3. Resolution:1024?RGB?x 768
4. Luminance:600nit
5. Backlight: LED
6. Power?supply:3.3v(Typ.)
Specifications
Module number | G121X1-L03 |
Resolution | 1024 x R.G.B. x 768 |
Pixel Pitch | 0.240(H) x 0.240(V)(mm) |
Active Area | 245.76(H) x 184.32(V)(mm) |
View angle | R/L/U/D 80/80/70/70 (Deg) |
Pixel Arrangement | R.G.B. Vertical Stripe |
Surface Treatment | Hard coating (3H), Glare |
Electrical Interface | LVDS |
Brightness | 600 (cd/m2) |
Contrast ratio | 700:1 |
Outline dimension | 260.5(H)x 204(V) x 8.4(D)(mm)(Typ.) |
Gross weight | 510g(Typ.) |
Backlight | LED |
Response time | 16(ms) |
Display mode | TN,?Normally white |
Operate temperature | -30-80? (°C) |
Storage temperature | -40-85(°C) |
Display Colors | 262k/16.2M |
Power Supply Voltage | 3.3v |
Module Power Consumption | 11.8W(Typ.) |
Backlight lifetime | 50k hrs(Min.) |
Main Models of CMI as follows:
G070Y3-T01 | G121X1-L04 | AT043TN25 V.2 | AT065TN14 |
G070Y2-T02 | G121I1-L01 | AT043TN24 V.7 | AT070TN94 |
G070Y2-L01 | G150X1-L03 | EJ050NA-01G | AT080TN64 |
G080Y1-T01 | G150XGE-L04 | AT056TN52 V.3 | EJ080NA-05B |
G104X1-L03 | G185BGE-L01 V1.0 | AT056TN53 V.1 | ZJ090NA-03B |
G104X1-L04 | G133IGE-L03 | AT070TN83 V.1 | EJ101IA-01F |
G104S1-L01 | G154I1-LE1 | G057VGE-T01 | AT102TN03 V.9 |
G104V1-T03 | AT102TN03 V8? | G057AGE-T01 | AT102TN03 V.8 |
G121X1-L03 | LQ035NC111 | AT070TN92 | LSA40AT9001 |
G121S1-L02 | ? | ? | ? |
