Home > Products > Blister Sealing Machine > 27.12MHZ / 15KVA Automatic feeding High frequency plastic box folding / making Machine
27.12MHZ / 15KVA Automatic feeding High frequency plastic box folding / making Machine
- 0 Square Meter / Square Meters per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
PVC Plastic box soft creasing Machine, feeding and collecting simultaneously
-
8000W High Frequency Toothbrush Blister Sealing Machine with Manual Operation
-
35W / 60Hz Jewelry Home Ultrasonic Cleaner / Ultrasonic Jewellery Cleaners for Bracelets, Coins, Wat
-
28khz Industrial Ultrasonic Cleaning Machine With Ultrasonic Generator
-
40KHz , 80KHz automatic TFT industrial ultrasonic cleaning machine for up-market LCD glass cleaning
-
Lower cost automatic industrial ultrasonic cleaning machine with steam cleaning and vacuum drying
Product Details
| Brand Name | Ke-beige | Place of Origin | China | |
| Model Number | KBG-8000P |
Product Description
Certification:CE
27.12MHZ / 15KVA Automatic feeding High frequency plastic box folding / making Machine
Mainly Application:
Applied for PVC, APET, PETG, GAG, PP etc. materials soft crease box making under continuous operation in application of high frequency welding and folding.
High frequency plastic box folding machineFeatures:
Embossing and welding with PVC, EVA, PU, PE, TGA, PET, GAG, PP materials,
Automatic feeding material, adjustable operating speed,
Electronic counting, continuous automatic feeding speed, suitable for different materials, optional with expending set,
Imported abrasion proof transformation, avoid damaging the mould,
Photo-electricity induction, feeding-collection simultaneously, precise-controlled.
High frequency plastic box folding machine Specifications:
|
Model |
KBG-8000 P |
|
Power Voltage |
3φ380VAC 50HZ |
|
Input Power |
15KVA |
|
H.F Output Power |
8KW |
|
H.F Frequency |
27.12MHZ |
|
Rectifier |
SILICON DOIDE 2CL |
|
Oscillation tube |
7T69RB |
|
Electrode gap |
150mm |
|
Operation |
Pneumatic / Hydraulic |
|
Max. pressure |
20T |
|
Dimensions |
1433×5416×1700 mm (L×W×H) |
|
Upper mould ?plat |
560mm×560mm |
|
Down mould ?plat |
650mm×650mm |
