90KW Explosion-proof Oil Temperature Control Unit Machine , 300 Degree

Brand Name	AODE		Place of Origin	China
Model Number	AEOT-75BF-90

Delivery Time:Within 20days after receiving deposit
Certification:CE|ISO

90KW Explosion-proof Oil Temperature Control Unit Machine , 300 Degree

Quick Detail:

1. Explosion-proof isolated

2. Electric box external charged accessories explosion-proof

3. Explosion-proof equipment(optional)

4. Certification:CE & ISO

5. Pump pressure:5.0Kg/cm2

6. Pump power: 5.5KW

7. Alarm function:pump reversal,Oil shortage, overheating, overload ,oil spill, abnormal heating alarm and trip power outage

Description:

Explosion-proof isolated electrical box Electric box external charged accessories explosion-proof Explosion-proof equipment Air blowing and return oil function(optional) Thermometer for return oil Automatic air-exhausting function after startup Switchover of heating power Negative-pressure system(optional) RS485 communication function for automated management(optional) Delay cooling shut-down function(optional) BY-PASS pressure release loop for hot oil Customizable multi-point temperature control unit Customizable horsepower and heating power of oil pump Brands OMRON, FUJI, TE, LG, MOELLER, ABB, and WEST for electric appliances Range of temperature control: +25℃-300℃ for incoming water CE certificate Stainless steel integrated pipelines for less pipe resistance and rust Control mode: imported microcomputer or PLC(optional) Perfect safety protection, fault display, easy repair and maintenance even free of professionals

Specifications:

ITEM	UNIT	AEOT-75BF-90
Temp control range	℃	Normal temp-300℃
Temp control accuracy	℃	PID±1℃
Power supply		AC3∮380V(3Phase+Earth)
Heat transfer medium		Thermo conductive oil
Cooling method		Without Cooling
Expansion Tank	L	150(External)
Heating capacity	KW	80(40+40)/90(45+45)
Pump power	KW	5.5
Pump flow	M3/h	12.5(18)
Pump pressure	Kg/cm2	5.0(4.0)
Max. power consumption	KW	96
Alarm function		Pump reversal/Oil shortage/Overheating/Overload/Oil spill/Abnormal heating alarm/trip power outage
Cooling water pipe	inch	NA
Circulating oil pipe	inch	1-1/2
Size(L×W×H)	mm	2250×800×1800
Heat pipe size/ length+ flange outer diameter	L×φ	1650×φ520

Competitive Advantage:

1. Strict quality control system

2. Three factories in shenzhen, tianjin and suzhou. More than 60 offices in China.

3. Our product is environmental and energy-saving

4. We have the production certification organic heat transfer material heater

5. High density heat insulation cotton and aluminum foil

6. Electric appliances brands:OMRON, JUJI, TE.LG, MOLLER, ABB and WEST

7. Imported microcomputer or PLC

8. Customization thick copper pipe 1
