Home > Products > Camera Top Monitor > Histogram Exposure HDMI Camera Top Monitor With Pixel to Pixel Lilliput 7 inch monitor
Histogram Exposure HDMI Camera Top Monitor With Pixel to Pixel Lilliput 7 inch monitor
Negotiable
/ Piece
1 Piece(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Color / RGB Histogram 400cd/m2 HD Field Monitor / Lilliput HDMI Monitor
-
Lilliput USB 2.0 IPS Screen Video Dual Rack Mount Monitor With 3G SDI
-
Professional FPV LCD Monitor 5.8GHz With Wireless AV Receive Lilliput 7 inch Monitor
-
Wireless Touchscreen 7inch Industrial Panel PC Comply with IP64 600MHz processor
-
GK7000 7 inch Touch Mobile Portable Data Terminal With SD Card / Earphone output
-
Mini Lilliput Full HD Capacitive Multi Touch Monitor With HDMI Input
Product Details
| Brand Name | LILLIPUT | Place of Origin | China | |
| Model Number | 664/P |
Product Description
Certification:CE / FCC
Histogram Exposure HDMI Camera Top Monitor With Pixel to Pixel Lilliput 7 inch monitor
Lilliput 664/P 7\" Camera Top Monitor With HDMI Input
IPS panel wide viewing angles Shutter shortcut button 178° Wide viewing angles High resolution: 1280 × 800 High brightness: 400cd/m2 High contrast: 800: 1 Faster response time Wide voltage: DC 7-24V Slimmer designAdvanced Functions:
Level Meter , Peaking Filter, False Colors, Histogram, Exposure, Camera Mode, Center Marker, Pixel-to-Pixel, Color Bar, Screen Marker, Aspect Ratio, Check Field, Underscan/Overscan, Freeze Input, H/V Delay, 8x Zoom, Picture-in-Picture, Flip H/V, Backlit Control.
Values can be adjust under level meter, peaking & exposure functions,etc.
| Panel | 7” IPS |
| Physical Resolution | 1280× 800, support 1920× 1080 |
| Aspect Ratio | 16:9 |
| Brightness | 400cd/m2 |
| Contrast | 800:1 |
| Viewing Angle | 178° / 178° (H/V) |
| Input Signal | HDMI , AV |
| Audio | Speaker×1(built-in), Ear Phone Slot×1(built-in) |
| Current | 960mA |
| Input Voltage | DC 7-24V |
| Battery Plate | V-mount, Anton Bauer mount, F-970, QM91D, DU21, LP-E6 |
| Power Consumption | ≤ 12W |
| Operating Temperature | -20o C ~ 60o C |
| Storage Temperature | -30o C~ 70o C |
| Dimension(LWD) | 184.5×131×23mm |
| Weight | 375g |
Accessories:
| Folding sun shade cover | 1 piece |
| Shoe mount | 1 piece |
| Battery plate (F-970, QM91D, DU21 or LP-E6) | 2pieces |
| HDMI A/C cable | 1 piece |
| DC 12V adapter | 1 piece |
| Composite cable | 1 piece |
| Shutter release cable | 2 pieces |
| Manual | 1copy |
| Battery plate bracket | 1 piece |
| V-mount battery plate(optional) | 1 piece |
| Anton Bauer mount battery plate(optional) | 1 piece |
| Suitcase(optional) | 1 piece |
