High Gain Indoor PCS Signal booster Repeater , wifi cellular repeater system Noise figure 4dB

High Gain Indoor PCS Signal booster Repeater , wifi cellular repeater system Noise figure ≤ 4dB

Quick Detail:

Mobile PCS Signal Booster, Cell Phone Repeaters, Boosters, AC 100 - 220V Home Cell Phone Signal Booster Amplifier, PCS 1900MHz Booster, Luxury Boat Repeaters, PCS 1900MHz Mobile Phone Signal Repeater Booster

Scope:

1. Small regions of signal or weak signal blind area, such as underground or semi-underground place of business, basements, underground parking, etc.;

2. Complaints from small-scale hot-signal areas, such as conference rooms, a small supermarket, small shopping malls, the office and small public areas, etc.;

3. Traffic and social influence of large areas, such as bars, cafes, dance halls, cafes, fitness clubs, leisure and entertainment, etc.;

4. Elevator, lift wells in particular, not in the lift cables laid;

5. Home, office, luxury yachts, private cars, public security system and road safety management, etc

Description:

Cell phone signal amplifier (also named repeater or booster) is a product designed to solve the mobile phone blind or weak signal. Inside of some tall buildings, the basement of some places such as malls , restaurants , places of entertainment such as Karaoke OK sauna and massage, subway stations and many other places where cell phone signals can not reach and can not use the phone. Cell phone signal amplifier can solve these problems.

Our cellular repeaters and boosters overcome the problem of dropped calls, limited range and slow data rates for cell phones and data cards by amplifying weak cellular signals, increasing your transmission and reception signal, and particularly in regions where there is a poor signal or very low signal coverage.

They provide benefits including improved reception and fewer dropped calls, lower radiation levels from your cell phone, and longer cell phone battery life.

Applications:

Cellular repeaters and boosters can be used at home, in the office, and in industrial applications in order to improve the reception for a single product or deployed to improve a whole local network region.

Specifications:

Working Voltage: AC 100-220V(used AC/DC? 9Vdc)

Frequency Range: 1850-1910MHZ(UP),1930-1990MHZ(DOWN)

Gain: 55dB Power: 20dbm

Pass Band Ripple : ≤3dB

Noise figure: ≤4dB

VSWR: ≤1.5(V.S.W.R)

Group Delay: 0.5μs

Size: (H x W x D): 198x 130 x 23 mm

Built-overarea : 200 m2

Competitive Advantage:

Our products are available as easy to fix, or you can custom configure your own cellular repeater system for your unique application by choosing specific AM booster, antennas and other wireless products or accessories.
